SWIFT 35 Control Board Assembly

#PartDescriptionPriceReqNotesAvailability
101 192-4125 Handle $250.13 1 usually ships 19-25 days
102 192-3866 Handle front $21.67 1 usually ships 1-5 days
103 192-6953 Switch lever $5.84 2 usually ships 1-5 days
104 192-0681 Microswitch $14.18 2 usually ships 19-25 days
105 192-0452 Screw for plastic KA 30 x 16mm $2.56 9 usually ships 19-25 days
106 192-3816 Foil $37.05 1 usually ships 19-25 days
107 192-6098 Rocker switch $4.49 2 usually ships 19-25 days
108 192-0559 Pressure spring $2.44 2 usually ships 19-25 days
109 192-0954 3 way connection block $3.97 1 usually ships 19-25 days
111 192-5485 Pictograph $10.13 1 usually ships 1-5 days
112 192-5546 Plate $3.28 1 usually ships 1-5 days
113 192-2492 Cable bushing $14.74 1 usually ships 1-5 days
114 192-5332 Nut $2.44 1 usually ships 1-5 days
115 192-2496 Cable clamp $2.56 2 usually ships 19-25 days
120 192-2435 Cable $98.85 1 usually ships 19-25 days
121 192-1829 Handle back $21.67 1 usually ships 1-5 days
122 192-6286 Screw KA 40 x 18 $2.56 10 usually ships 19-25 days
124 192-6915 Swing support $15.72 4 usually ships 19-25 days
125a 192-0899 Screw M6 x 25mm hex head $3.80 4 Series 02 ships same day
125b 192-1285 Screw M6 x 25mm hex head $2.56 4 Series 01 ships same day
126 999-1308 Nut M6-1 hex stainless steel $0.99 5 ships same day
129 192-4289 Handle $15.85 1 usually ships 19-25 days
130 192-1884 Bar $44.36 1 usually ships 19-25 days
131 192-5505 Pipe $32.18 1 usually ships 1-5 days
132 192-4747 Lever $17.69 1 usually ships 19-25 days
133 192-1761 Axle $8.80 1 usually ships 19-25 days
134a 999-0471 Nut M8-1.25 nylon insert lock zinc plated $0.99 1 Series 02 ships same day
134b 192-0718 Hex cap $2.56 1 Series 01 usually ships 1-5 days
135 192-2365 Bushing $11.87 1 usually ships 19-25 days
136 192-2140 Bracket $325.64 1 ships same day
137 192-0649 Wheel (includes hubcap) $33.08 2 Includes cap usually ships 19-25 days
139 192-4234 Screw M8 x 70 hex head $2.56 2 ships same day
141 192-0648 Bushing $19.82 2 usually ships 19-25 days
142a 192-7427 Washer $4.95 5 Series 02 usually ships 19-25 days
142b 192-0647 Washer $5.26 5 Series 01 ships same day
144 192-3340 Spacer $5.26 4 usually ships 19-25 days
145 192-8576 Ring $11.02 1 usually ships 19-25 days
146 192-2507 Cable clip $3.72 5 usually ships 1-5 days
148 192-4228 Screw M8 x 16mm hex head $2.44 1 usually ships 19-25 days
149 192-3404 Dummy element $2.64 1 usually ships 19-25 days
150 192-6668 Star cap $2.56 2 usually ships 19-25 days
151 N/A Not available Call for price 1 (Bottle holder) usually ships 3-26 days
152 192-0160 Screw M5 x 10mm raised head $3.66 2 usually ships 19-25 days
153 192-2112 Bottle 1/2 L $15.05 1 usually ships 1-5 days
154 192-5425 Packing strip $5.90 1 usually ships 1-5 days
159 192-2591 Nut M8 caged $2.56 1 Series 01 ships same day
160 192-4927 Main cord 120 volt 14/3 $113.41 1 ships same day
161 192-0569 Hook (OBSOLETE) $2.88 1 usually ships 19-25 days
162 N/A Not available Call for price Cap usually ships 3-26 days
N/S 192-3434 Earth symbol (OBSOLETE) $2.44 1 usually ships 1-5 days
N/S 192-4686 Label $2.56 1 usually ships 1-5 days
N/S 192-6992 Filter label $2.56 1 usually ships 19-25 days
