| # | Part | Description |
Req | Notes | Availability |
|---|
101 |
292-0082
|
Filter kit |
1 |
|
|
102 |
292-0082
|
Filter kit |
1 |
|
|
103 |
292-0082
|
Filter kit |
1 |
|
|
104 |
192-0915
|
Nut M4 square |
10 |
|
|
105 |
192-0919
|
Valve flange (OBSOLETE) |
1 |
|
|
106 |
192-0914
|
Gasket |
3 |
|
|
107a |
192-0917
|
24V magnetic valve (OBSOLETE) |
1 |
|
|
107b |
N/A
|
Not available |
|
Repair set valve |
|
108 |
192-0911
|
Flange |
3 |
|
|
109 |
192-0913
|
Nipple |
1 |
|
|
110 |
192-0910
|
Filter housing |
1 |
|
|
111 |
192-0916
|
Angled nipple |
2 |
|
|
112 |
192-0912
|
Screw M4 x 16mm raised head |
8 |
|
|
113 |
192-0149
|
Washer |
8 |
|
|
114 |
192-1270
|
Intermediate plate |
1 |
|
|
115 |
192-1271
|
Gasket |
1 |
|
|
116 |
192-1272
|
Filter insert |
1 |
|
|
