PF70DC Base and Hood Assembly

#PartDescriptionPriceReqNotesAvailability
1 N/A Not available Call for price 1 (shoulder screw) usually ships 3-26 days
2 993-0664 Knob $9.30 1 usually ships 1-5 days
3 190-9173 Hood assembly (blue) $56.11 1 usually ships 15-28 days
4 190-1154 Rear axle screw $1.30 1 usually ships 15-28 days
6 190-1151 Screw $1.35 1 usually ships 15-28 days
7 182-0009 120V vacuum motor assembly $69.67 1 ships same day
11 190-1150 Screw $1.35 1 usually ships 15-28 days
12 190-1168 Front axle screw and clamp assembly $5.50 1 usually ships 15-28 days
13 993-1727 COVER, WHEEL $3.26 1 usually ships 1-5 days
14 190-9174 Base assembly $184.68 1 usually ships 15-28 days
20 190-9175 Bracket bushing $17.86 1 usually ships 15-28 days
21 182-0017 Strain relief bushing $5.71 1 usually ships 12-20 days
22 190-1152 Switch button $6.63 1 usually ships 15-28 days
23 190-1153 Switch clip $7.85 1 usually ships 15-28 days
25 190-1087 On/off switch $15.39 1 usually ships 15-28 days
28 993-0675 Gasket $1.50 1 usually ships 1-3 days
29 993-1710 PEDAL, FOOT $6.90 1 usually ships 1-5 days
30 993-0818 FOOT PEDAL SPRING $0.90 1 usually ships 1-5 days
31 190-9175 Bracket bushing $17.86 1 usually ships 15-28 days
32 190-9177 Bellows $43.37 1 usually ships 15-28 days
