CMBP-6 Entire Assembly

#PartDescriptionPriceReqNotesAvailability
1 190-1502 Thermal protection switch $12.56 1 (Thermal protection switch) usually ships 20-37 days
2 190-0610 Lid latch $6.59 1 (Latch) usually ships 10-27 days
3 N/A Not available Call for price 4 (Screw) usually ships 3-26 days
4 N/A Not available Call for price 2 (Screw) usually ships 3-26 days
5 190-0505 Upper cord hook screw $1.30 4 usually ships 20-37 days
6 190-1494 Screw $1.35 4 usually ships 20-37 days
7 190-0686 Backplate (no straps) $14.05 1 usually ships 10-27 days
8 190-0462 Exhaust filter $8.54 1 usually ships 20-37 days
9 190-0450 Cloth bag $20.89 1 (Paper bags) ships same day
10 189-7558 Power harness $28.80 1 usually ships 11-24 days
11 190-1496 Seal $1.35 1 usually ships 20-37 days
12 189-7612 Strain relief $14.06 2 usually ships 11-24 days
13 N/A Not available Call for price 2 (Nut) usually ships 3-26 days
14 190-1497 Motor compartment $14.81 1 usually ships 20-37 days
15 N/A Not available Call for price 1 (Bumper) usually ships 3-26 days
16 N/A Not available Call for price 1 (Front plate) usually ships 3-26 days
17 N/A Not available Call for price 1 (Back plate) usually ships 3-26 days
18 190-1495 Cover $15.44 1 (Cover) usually ships 20-37 days
19 189-5176 Hose inlet $14.25 1 usually ships 11-24 days
20 190-0465 Motor cover $8.84 1 ships same day
21 N/A Not available Call for price 1 (Secondary filter plate) usually ships 3-26 days
22 190-0461 HEPA filter $3.71 1 ships same day
23 190-0460 Filter frame cap $2.54 1 usually ships 20-37 days
24 190-0463 Bottom filter frame $6.59 1 usually ships 20-37 days
25 190-0464 Body seal $7.33 1 usually ships 1-5 days
26 190-1498 Bottom motor mount $5.50 1 usually ships 20-37 days
27 190-1499 Inlet seal $1.35 1 usually ships 20-37 days
28 190-0461 HEPA filter $3.71 1 ships same day
29 189-7559 Switch harness $27.61 1 ships same day
30 190-0459 Vacuum motor $115.49 1 ships same day
31 190-1500 Motor shroud $3.30 1 usually ships 20-37 days
32 N/A Not available Call for price 2 (Shoulder harness strap) usually ships 3-26 days
33 N/A Not available Call for price 1 (Waist belt) usually ships 3-26 days
34 N/A Not available Call for price 2 (Shoulder strap buckle) usually ships 3-26 days
35 190-0466 Motor mount kit $12.22 1 usually ships 1-5 days
36 190-1501 Motor shroud $7.34 1 usually ships 20-37 days
37 190-0467 Top motor shroud $8.04 1 usually ships 1-5 days
38 190-0468 Bottom motor mount $5.75 1 usually ships 20-37 days
39 N/A Not available Call for price 1 (Right hand shoulder harness) usually ships 3-26 days
40 N/A Not available Call for price 1 (Left hand shoulder harness) usually ships 3-26 days
