| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
190-0538
|
Nozzle housing assembly |
$30.79
|
1 |
|
usually ships 11-14 days |
2 |
190-0539
|
Furniture guard |
$5.50
|
1 |
|
usually ships 11-14 days |
3 |
190-9686
|
Screw #8-18 x 5/8 |
$3.95
|
8 |
|
usually ships 14-18 days |
4 |
190-0569
|
Belt |
$13.19
|
1 |
|
usually ships 11-14 days |
5 |
190-9038
|
Hall sensor ilder assembly |
$50.59
|
1 |
|
usually ships 11-14 days |
6 |
190-9039
|
Rear wheel assembly with axle |
$13.19
|
1 |
|
usually ships 11-14 days |
7 |
190-0542
|
Base assembly |
$47.29
|
1 |
(includes 3 and 24) |
ships same day |
8 |
190-9040
|
Base plate wheel assembly |
$6.59
|
1 |
|
usually ships 11-14 days |
9 |
190-0566
|
Metal brush roll assembly |
$87.99
|
1 |
|
usually ships 11-14 days |
9a |
190-0567
|
Short nylon strip |
$7.69
|
1 |
|
ships same day |
9b |
190-0568
|
Long nylon stirp |
$5.50
|
1 |
|
ships same day |
10 |
190-9041
|
Basetray cover w/squeegee |
$10.56
|
1 |
|
usually ships 11-14 days |
11 |
190-0546
|
Wheel |
$3.95
|
1 |
|
usually ships 11-14 days |
12 |
183-2402
|
Bottom plate axle |
$3.95
|
1 |
|
ships same day |
13 |
190-9042
|
Basetray cover squeegee |
$2.63
|
1 |
|
usually ships 11-14 days |
14 |
190-0551
|
Squeegee and baseplate upgrade kit |
$16.49
|
1 |
(includes 10-13) |
usually ships 11-14 days |
15 |
190-9044
|
Plastic dowel |
$3.95
|
1 |
|
usually ships 11-14 days |
16 |
190-9043
|
PC board |
$73.69
|
1 |
|
usually ships 11-14 days |
17 |
190-0550
|
Strain relief washer |
$3.95
|
1 |
|
usually ships 11-14 days |
18 |
190-0161
|
Screw for inlet tube |
$3.95
|
1 |
|
usually ships 11-14 days |
19 |
190-0548
|
Upright stop |
$3.95
|
1 |
|
usually ships 11-14 days |
