| # | Part | Description |
Req | Notes | Availability |
|---|
1a |
190-0048
|
120V 2 stage vacuum motor |
2 |
(PFX5 Qty 1) (PFX 10S and PFX15S Qty 2) |
|
1b |
190-0922
|
3 stage vacuum motor |
1 |
(PFX5S, PFX10, PFX15 only) |
|
2a |
190-0069
|
Flojet 2100 duplex diaphragm pump |
1 |
(PFX5, PFX5S and PFX10 only) |
|
2b |
N/A
|
Not available |
1 |
(100PSI pump) (PFX15, PFX10S and PFX15S only) |
|
3 |
190-0923
|
2 inch flexible hose |
1 |
|
|
4 |
190-0436
|
12/3 power cord SJTW 30 foot |
1 |
|
|
5 |
N/A
|
Not available |
1 |
(Heater) |
|
6 |
189-2494
|
Dump valve |
1 |
|
|
7 |
190-0570
|
Dump valve elbow |
1 |
|
|
8 |
189-2496
|
PVC drain elbow |
1 |
|
|
9 |
190-9023
|
Gasket |
1 |
|
|
10 |
189-2486
|
Vac inlet gasket |
1 |
|
|
11a |
190-0924
|
3 inch caster assembly |
1 |
|
|
11b |
N/A
|
Not available |
1 |
(Wheel) |
|
12 |
189-8628
|
Insulation switch boot |
1 |
|
|
13 |
190-0925
|
Handle |
1 |
|
|
14 |
N/A
|
Not available |
1 |
(Screw) |
|
15 |
190-0926
|
Mesh screen filter |
1 |
|
|
16a |
216-0325
|
Float cage with ball |
1 |
|
|
16b |
190-0927
|
Float cage with ball |
1 |
(5 gallon tank) |
|
16c |
N/A
|
Not available |
1 |
(Float cage) (old style) |
|
17 |
190-0684
|
Vacuum tube |
1 |
|
|
18 |
190-0928
|
Lid hinge |
1 |
|
|
19 |
190-0870
|
Nut lock |
1 |
|
|
20 |
190-0929
|
Receptacal molded wire |
1 |
|
|
21 |
216-0019
|
Quick disconnect valve |
1 |
|
|
22 |
N/A
|
Not available |
1 |
(Bumper clamp) |
|
23a |
190-0930
|
Lid with gasket |
1 |
(10 and 15 gallon) |
|
23b |
N/A
|
Not available |
1 |
(Lid and gasket) (5 gallon) |
|
23c |
N/A
|
Not available |
1 |
(Lid and gasket assembly) (5 gallon) |
|
23d |
190-0931
|
Lid assembly |
1 |
(10 and 15 gallon after SN 600 and SN 7000) |
|
23e |
N/A
|
Not available |
1 |
(Lid assembly) (before SN 4000 and 5000) |
|
24 |
190-0932
|
Foam gasket |
1 |
|
|
25 |
N/A
|
Not available |
1 |
(Vent) |
|
26 |
N/A
|
Not available |
1 |
(Gasket) |
|
27 |
190-0272
|
Switch |
1 |
|
|
29a |
190-0933
|
Bottom cover |
1 |
|
|
29b |
190-0934
|
Bottom cover |
1 |
|
|
30 |
190-0935
|
Cord wrap bracket |
1 |
|
|
31 |
190-0936
|
Frame |
1 |
|
|
32 |
190-0937
|
Motor bracket (OBSOLETE) |
1 |
|
|
33 |
N/A
|
Not available |
1 |
(Heater bracket) |
|
34 |
190-0938
|
Cord protector |
1 |
|
|
35 |
216-0068
|
Hose barb |
1 |
|
|
36a |
N/A
|
Not available |
1 |
(Fiberglass housing) (5 gallon) |
|
36b |
190-0939
|
10 gallon fiberglass housing |
1 |
(10 gallon) |
|
36c |
190-0940
|
15 gallon fiberglass housing |
1 |
(15 gallon) |
|
