| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
189-8230
|
Heavy duty key switch with 2 keys |
1 |
|
|
2 |
189-2283
|
BDI (battery level indicator with hour meter) |
1 |
|
|
3 |
999-0028
|
Washer 5/16 split lock plain finish |
1 |
|
|
4 |
189-2277
|
Pan Head Screw 20 1/4 x 1 inch |
1 |
|
|
5 |
189-2284
|
Switch box bracket |
1 |
|
|
6 |
189-4407
|
36V contactor (OBSOLETE) |
1 |
|
|
7 |
203-1800
|
Screw 10 x 25 inch |
1 |
|
|
8 |
189-7632
|
50amp circuit breaker |
1 |
|
|
9 |
189-6345
|
10amp circuit breaker |
1 |
|
|
10 |
189-2286
|
Hex head screw 20 1/4 x 1/2 inch |
1 |
|
|
11 |
189-2287
|
Washer SAE 1/4 inch |
1 |
|
|
12 |
189-2288
|
Wire 18 awg 4 inch (red) |
1 |
|
|
13 |
189-2289
|
Wire 16 awg 6 inch |
1 |
|
|
14 |
189-2290
|
Cable 6 awg 6 inch (red) |
1 |
|
|
15 |
189-2291
|
Screw phillips head #M4 x 6 |
2 |
|
|
16 |
189-2292
|
Key switch |
1 |
|
|
17 |
189-2293
|
Spacer 1/4 x 5/8 x 5/16 inch |
1 |
|
|
18 |
189-2294
|
1/32 inch garolite strip |
1 |
|
|
