| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
189-6360
|
Hour meter |
1 |
|
|
2 |
189-6341
|
Key switch assembly with keys |
1 |
|
|
10 |
189-7554
|
Relay card |
1 |
|
|
11 |
991-9284
|
50amp charger plug SB50 with pins (red) |
1 |
|
|
14 |
189-7576
|
Solenoid valve |
1 |
|
|
15 |
189-6368
|
30amp electrical connector |
1 |
|
|
16 |
189-6368
|
30amp electrical connector |
1 |
|
|
MI1 |
189-6349
|
Microswitch |
1 |
|
|
MI2 |
189-6349
|
Microswitch |
1 |
|
|
MI3 |
189-6369
|
Microswitch |
1 |
|
|
MI4 |
189-6369
|
Microswitch |
1 |
|
|
M1 |
189-6370
|
24V brush motor |
1 |
|
|
M2 |
289-0081
|
24V vacuum motor |
1 |
|
|
