| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
189-6195
|
Splash guard |
1 |
|
|
2 |
189-6196
|
Brush deck |
1 |
|
|
3 |
189-6197
|
Bushing |
3 |
|
|
4 |
999-0248
|
Bolt M8-1.25 x 30mm hex head full thread plain finish |
3 |
|
|
5 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
3 |
|
|
6 |
189-6198
|
Flat washer |
8 |
|
|
