| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
189-1819
|
Plastic fitting for seat |
1 |
|
|
002 |
189-1843
|
Nut M5 |
3 |
|
|
003 |
189-1820
|
Tap clamp |
2 |
|
|
004 |
189-1821
|
Screw 5x25 cross slotted |
3 |
|
|
005 |
189-1822
|
Lever tap |
1 |
|
|
006 |
189-1823
|
Rubber gasket 15x9.5x1.5 |
3 |
|
|
007 |
189-1824
|
Nozzle filter stainless steel |
3 |
|
|
008 |
189-1825
|
Nozzle |
1 |
|
|
009 |
189-1826
|
Nut 3/8 plastic ring |
3 |
|
|
010 |
189-1827
|
Flex pipe for water 3m |
1 |
|
|
011 |
189-1828
|
Plastic pipe curve |
1 |
|
|
012 |
189-1829
|
Lever tap |
1 |
|
|
013 |
189-1830
|
Pipe 36x490 stainless steel |
2 |
|
|
014 |
189-1831
|
Nozzle clamp |
1 |
|
|
015 |
189-1832
|
Nozzle extension |
1 |
|
|
016 |
189-1833
|
Nozzle |
1 |
|
|
017 |
189-1834
|
Slide support |
1 |
|
|
018 |
189-1835
|
Dust-proof strip support |
1 |
|
|
019 |
189-1836
|
Sucker holder slide |
1 |
|
|
020 |
189-1837
|
Carpet washer slide |
1 |
|
|
021 |
189-1838
|
Center strip slide |
1 |
|
|
022 |
189-1839
|
Floor washer outlet with pipe |
1 |
|
|
023 |
189-1840
|
Screw 4.8x22 self tapping |
2 |
|
|
024 |
189-1841
|
Tap with extension |
1 |
|
|
025 |
189-1842
|
Nozzle |
2 |
|
|
026 |
189-1844
|
1/4 inch accessory coupling |
1 |
|
|
027 |
189-1845
|
Complete plastic fitting for seat |
1 |
|
|
028 |
189-1846
|
Complete floor washer outlet with pipe |
1 |
|
|
029 |
189-1847
|
Complete floor/carpet cleaning wand |
1 |
|
|
030 |
189-1848
|
Complete floor/carpet cleaning wand + FLEX pipe |
1 |
|
|
