| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
189-8542
|
Oil pressure switch with 2 prongs |
1 |
|
|
2 |
169-0016
|
Key switch assembly with two keys |
1 |
|
|
3 |
991-6002
|
12V fuel lock off (Model 152) |
1 |
|
|
4 |
178-0265
|
Voltage regulator |
1 |
|
|
5 |
189-0801
|
14 gauge wire (black) |
2 |
|
|
6 |
162-0007
|
12V 12Ah sealed battery |
1 |
|
|
7 |
204-0120
|
12V solenoid |
1 |
|
|
8 |
189-3086
|
Hour meter |
1 |
|
|
9 |
189-0704
|
6 gauge wire (black) |
1 |
|
|
10 |
178-7106
|
Electric starter |
1 |
|
|
11 |
189-8047
|
Battery cable (red) |
2 |
|
|
12 |
189-8544
|
Emissions shutdown module with oxygen sensor |
1 |
|
|
13 |
189-8544
|
Emissions shutdown module with oxygen sensor |
1 |
|
|
