| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
189-8518
|
Hose (vac to tank) |
1 |
|
|
2 |
189-5100
|
Recovery tank lid assembly |
1 |
|
|
3 |
999-9096
|
Screw M5-.8 x 12mm socket head stainless steel |
4 |
|
|
5 |
189-9060
|
Latch |
2 |
|
|
6 |
189-8691
|
1/4 female quick disconnect |
1 |
|
|
7 |
189-8517
|
Hose (squeegee to tank) |
1 |
|
|
8 |
189-8615
|
Solution tank |
1 |
|
|
9 |
189-9061
|
Recovery tank |
1 |
|
|
10 |
189-8692
|
Solution tank lid |
1 |
|
|
11 |
189-7560
|
O-ring |
1 |
|
|
12 |
189-8693
|
Wheel cap |
2 |
|
|
13 |
189-9062
|
Rubber cap |
1 |
|
|
14 |
189-9063
|
Inlet filter |
1 |
|
|
15 |
189-9064
|
Battery charger cover |
1 |
|
|
16 |
189-8690
|
Filter flange |
1 |
|
|
17 |
189-4369
|
Filter gasket |
1 |
|
|
18 |
189-9057
|
Hose clamp |
1 |
|
|
19 |
189-8686
|
Grommet |
1 |
|
|
20 |
189-9058
|
Recovery tank cap |
1 |
|
|
21 |
189-8683
|
Vacuum elbow fitting |
1 |
|
|
22 |
189-8684
|
Vacuum elbow fitting (long) |
1 |
|
|
23 |
189-8685
|
Grommet |
1 |
|
|
24 |
189-9059
|
Air filter/shutoff |
1 |
|
|
