| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
189-0144
|
Plaque |
2 |
|
|
002 |
189-0081
|
Ring |
2 |
|
|
003 |
203-3263
|
Bearing |
2 |
|
|
004 |
189-0146
|
Pulley |
1 |
|
|
005 |
189-0147
|
Bearing |
2 |
|
|
006 |
189-0148
|
Pin/plug |
1 |
|
|
007 |
189-1487
|
Washer |
8 |
|
|
008 |
189-1477
|
Washer cham |
7 |
|
|
009 |
189-1489
|
Nut M6 |
3 |
|
|
010 |
189-0149
|
Ring |
1 |
|
|
011 |
189-1488
|
Screw M6 |
3 |
|
|
012 |
189-0150
|
Bearing |
2 |
|
|
013 |
189-2442
|
Spacer |
1 |
|
|
014 |
189-0152
|
Belt |
1 |
|
|
015 |
189-0153
|
Tang-tongue |
2 |
|
|
016 |
189-0158
|
Belt |
1 |
|
|
017 |
189-0157
|
Pulley |
1 |
|
|
018 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
1 |
|
|
019 |
189-1512
|
Screw 8 x 20 inch |
2 |
|
|
020 |
189-2438
|
Shaft |
1 |
|
|
021 |
189-0155
|
Motor |
1 |
|
|
022 |
189-0849
|
Support |
1 |
|
|
023 |
189-1497
|
Screw 6 x 16 inch |
4 |
|
|
024 |
189-1497
|
Screw 6 x 16 inch |
1 |
|
|
025 |
189-0850
|
Pulley |
1 |
|
|
026 |
189-0897
|
Washer D8 |
8 |
|
|
027 |
189-1511
|
Washer |
5 |
|
|
028 |
189-1370
|
Screw |
1 |
|
|
029 |
189-1492
|
Nut M8 |
1 |
|
|
030 |
189-0156
|
Flange |
1 |
|
|
031 |
189-0851
|
Bearing |
2 |
|
|
032 |
375-9702
|
Screw M8 x 50 inox |
2 |
|
|
