| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
189-1494
|
Screw |
2 |
|
|
002 |
189-1487
|
Washer |
11 |
|
|
003 |
189-1495
|
Washer |
1 |
|
|
004 |
189-0081
|
Ring |
1 |
|
|
005 |
189-0082
|
Bushing |
2 |
|
|
006 |
189-0083
|
Hose |
1 |
|
|
007 |
189-0829
|
Bearing (OBSOLETE) |
3 |
|
|
008 |
189-1489
|
Nut M6 |
2 |
|
|
009 |
203-0524
|
Nut M6 lock |
2 |
|
|
010 |
189-0084
|
Clamp |
1 |
|
|
011 |
189-0085
|
Hose |
1 |
|
|
012 |
189-0086
|
Gasket |
1 |
|
|
013 |
189-1348
|
Screw |
1 |
|
|
014 |
189-1477
|
Washer cham |
1 |
|
|
015a |
189-1496
|
Vacuum motor |
1 |
|
|
015b |
991-1203
|
24V 2 stage vacuum motor tangential |
1 |
(NON-OEM) |
|
016 |
189-0897
|
Washer D8 |
1 |
|
|
017 |
189-0830
|
Suction conveyor |
1 |
|
|
018 |
189-0087
|
Gasket |
1 |
|
|
