| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
NOTE
|
Please See Batteries, Brushes, Pad Holders and Charger Pages |
|
|
|
003 |
991-2206
|
Center-Lok 3 pad holder |
|
|
|
004 |
173-3916
|
Screw 1/4-20 x 5/8 phillips pan head thread cutting ss |
|
|
|
005 |
173-3917
|
Screw 8 x 1/2 phillips pan head stainless steel |
|
|
|
006 |
173-3916
|
Screw 1/4-20 x 5/8 phillips pan head thread cutting ss |
|
|
|
007 |
173-1558
|
Extension spring |
|
|
|
008 |
173-1023
|
Hex drive clutch (OBSOLETE) |
|
|
|
009 |
173-1022
|
Brush release plate |
|
|
|
010 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
|
|
|
N/S |
189-6184
|
Socket drive clutch |
|
|
|
