| # | Part | Description |
Req | Notes | Availability |
|---|
002 |
999-0952
|
Nut 1/4-28 hex stainless steel |
1 |
|
|
003 |
173-1039
|
Cotter Pin 1/16 x 3/4 |
1 |
|
|
004 |
173-1474
|
Clevis pin |
1 |
|
|
005 |
173-2880
|
Roll pin |
2 |
|
|
007 |
173-1477
|
torsion brake rod |
1 |
|
|
008 |
999-0730
|
Bolt 5/16-18 x 2 1/2 hex head grade 5 zinc plated |
4 |
|
|
009 |
173-1478
|
Extension spring |
1 |
|
|
010 |
173-1479
|
Yoke end clevis |
1 |
|
|
011 |
173-1130
|
Cotter ring |
1 |
|
|
012 |
173-1480
|
Cotter ring |
2 |
|
|
013 |
173-1481
|
Clevis pin |
1 |
|
|
014 |
999-0630
|
Washer 3/4 SAE flat |
4 |
|
|
015 |
999-1007
|
Washer 3/8 x 1/16 flat nylon |
2 |
|
|
016 |
173-1482
|
brake pedal (OBSOLETE) |
1 |
|
|
017 |
173-1483
|
weldment rod parking brake (OBSOLETE) |
1 |
|
|
018 |
173-1484
|
brake pad (OBSOLETE) |
2 |
|
|
019 |
189-4010
|
Wheel with bearings |
1 |
|
|
020 |
173-1486
|
pillow block bushing (OBSOLETE) |
2 |
|
|
