| # | Part | Description |
Req | Notes | Availability |
|---|
09 |
190-0008
|
Handle clamp assembly |
|
|
|
13a |
189-8617
|
Pivot shaft |
|
|
|
13b |
999-0320
|
Screw 1/4-20 x 3/4 socket head alloy plain finish |
|
|
|
14 |
189-8618
|
Wheel axle |
|
|
|
15 |
999-0016
|
Washer 1/4 flat plain finish |
|
|
|
16 |
189-2987
|
5 inch wheel |
|
|
|
26 |
190-0267
|
Bumper |
|
|
|
27 |
999-0883
|
Screw 8 x 1 pan head phillips zinc plated |
|
|
|
67 |
190-0575
|
On/off switch |
|
|
|
N/S |
996-0209
|
15 inch nylon scrubbing brush |
|
|
|
