| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
183-9521
|
Cover |
1 |
|
usually ships 16-24 days |
2 |
183-4697
|
Protected switch (green) |
3 |
|
usually ships 16-24 days |
3 |
183-9362
|
Protected signal lamp (red) |
1 |
|
usually ships 16-24 days |
5 |
183-2428
|
Handlebar cover and screws |
1 |
(includes 6) |
usually ships 16-24 days |
6 |
183-8361
|
Screw |
2 |
|
usually ships 16-24 days |
7 |
183-4696
|
Key |
1 |
|
usually ships 16-24 days |
8 |
183-4695
|
Key switch |
1 |
(includes 7) |
usually ships 16-24 days |
9 |
183-8372
|
Switch flange |
1 |
|
usually ships 16-24 days |
10 |
183-8373
|
Switch contact |
1 |
|
usually ships 16-24 days |
14 |
183-8386
|
Nylon nut |
2 |
|
usually ships 16-24 days |
15 |
999-1337
|
Screw M6 x 50mm socket head |
4 |
|
usually ships 11-14 days |
17a |
183-8333
|
Handle cover |
1 |
|
usually ships 16-24 days |
17b |
183-2427
|
Handlebar body |
1 |
|
usually ships 16-24 days |
18 |
183-8375
|
Screw M4 x 45 |
2 |
|
usually ships 16-24 days |
19 |
183-9366
|
Protected switch (green) |
1 |
|
usually ships 16-24 days |
20 |
183-8378
|
Nut |
4 |
|
usually ships 16-24 days |
23 |
183-8336
|
Handle grip |
2 |
|
usually ships 16-24 days |
24 |
183-8396
|
Handle cap |
2 |
|
usually ships 16-24 days |
25 |
183-8340
|
Handle tube |
1 |
|
usually ships 16-24 days |
26 |
183-8341
|
Screw |
2 |
|
usually ships 16-24 days |
27 |
183-9523
|
Instrument board decal |
1 |
|
usually ships 16-24 days |
28 |
183-8381
|
Switch (Obsolete) |
1 |
(3S only) |
usually ships 16-24 days |
29 |
183-8380
|
Decal (Obsolete) |
1 |
(3S only) |
usually ships 16-24 days |
31 |
183-8334
|
Washer |
4 |
|
usually ships 16-24 days |
33 |
183-4697
|
Protected switch (green) |
2 |
|
usually ships 16-24 days |
34 |
183-8382
|
Washer |
4 |
|
usually ships 16-24 days |
35 |
183-8383
|
Rivet with screw |
1 |
|
usually ships 16-24 days |
36 |
183-8385
|
Cap |
6 |
|
usually ships 16-24 days |
