| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
183-9276
|
Screw M3 x 35mm |
1 |
|
|
2 |
183-4712
|
10amp microswitch |
2 |
|
|
3 |
183-8352
|
Nut |
1 |
|
|
4a |
183-9277
|
2.5K potentioneter |
1 |
(after SN 14003121) |
|
4b |
183-8332
|
Screw M5 x 8 |
1 |
(before SN 14003122) |
|
5 |
183-9278
|
Potentiometer nut |
1 |
|
|
6 |
183-8339
|
Lever |
2 |
|
|
7 |
183-8338
|
Washer |
1 |
|
|
8 |
183-8337
|
Screw M3 x 10 |
1 |
|
|
9 |
183-8357
|
Nut |
1 |
|
|
10 |
183-8350
|
Screw |
1 |
|
|
11 |
183-9279
|
Potentiometer level |
1 |
|
|
12 |
183-8354
|
Ring |
4 |
|
|
13 |
183-9280
|
Drive control tie rod |
1 |
|
|
14 |
183-8353
|
Lever |
2 |
|
|
15 |
183-8344
|
Bracket |
1 |
|
|
16a |
183-8330
|
Screw M5 x 8 |
1 |
(after SN 14003121) |
|
16b |
183-8332
|
Screw M5 x 8 |
1 |
(before SN 14003122) |
|
17 |
183-9373
|
Camshaft |
1 |
|
|
18 |
183-8343
|
Ring |
3 |
|
|
19 |
183-8348
|
Lever |
1 |
|
|
21 |
183-9281
|
Micro cam drive control |
2 |
|
|
22 |
183-8351
|
Bushing |
1 |
|
|
23 |
183-8346
|
Spring |
1 |
|
|
24 |
183-8347
|
Bushing |
2 |
|
|
25 |
183-8355
|
Spring |
1 |
|
|
26 |
183-8314
|
Nut |
1 |
|
|
27 |
183-5145
|
Support (OBSOLETE) |
1 |
|
|
28a |
183-9374
|
Screw M4.8 x 16mm |
1 |
(after SN 14003121) |
|
28b |
183-2619
|
Screw M5 x 16mm |
1 |
(before SN 14003122) |
|
29a |
183-8393
|
Washer |
1 |
(after SN 14003121) |
|
29b |
183-8206
|
Washer |
1 |
(before SN 14003122) |
|
30a |
183-9375
|
Drive control assembly |
1 |
(after SN 14003121) |
|
30b |
183-9946
|
Drive control assembly (OBSOLETE) |
1 |
(before SN 14003122) |
|
