BD 14/4 Squeegee Control Assembly From SN 10000720 to SN 15004066

#PartDescriptionPriceReqNotesAvailability
1a 183-2615 Squeegee arm assembly $238.21 1 (from SN 11003295 to SN 15004066) usually ships 8-21 days
1b 183-2620 Squeegee arm (OBSOLETE) Call for price 1 (from SN 10000720 to SN 11003294) usually ships 8-21 days
2 183-2616 Screw M5 x 30mm $1.97 1 usually ships 8-21 days
3a 183-2617 Nut (OBSOLETE) Call for price 1 (from SN 11003295 to SN 15004066) usually ships 8-21 days
3b 183-2621 Nut $1.30 1 (from SN 10000720 to SN 11003294) usually ships 8-21 days
4 183-8424 Nut $1.35 1 usually ships 8-21 days
5 183-2611 Brass bushing $11.52 1 usually ships 8-21 days
6 183-2612 Arm joint $20.23 1 usually ships 8-21 days
8 183-2539 Lock washer $1.35 1 usually ships 8-21 days
11a 183-2618 Screw M5 x 12mm $1.35 2 (from SN 11003295 to SN 15004066) usually ships 8-21 days
11b 183-2596 Screw M5 x 12mm $1.95 2 (from SN 10000720 to SN 11003294) usually ships 8-21 days
12 183-2578 Lock washer $1.35 2 usually ships 8-21 days
13 183-8206 Washer $1.35 2 usually ships 8-21 days
14 183-4713 Chain $3.43 1 usually ships 8-21 days
15 183-2145 Bolt arm stud $8.92 2 usually ships 1-5 days
16 183-2619 Screw M5 x 16mm $1.35 1 usually ships 8-21 days
17 183-8537 Washer $1.35 2 usually ships 8-21 days
18a 183-8314 Nut $1.35 1 (from SN 11003295 to SN 15004066) usually ships 8-21 days
18b 183-2623 Nut $1.35 1 (from SN 10003598 to SN 11003294) usually ships 8-21 days
N/S 183-2622 Squeegee arm weight (OBSOLETE) Call for price 1 (from SN 10003598 to SN 11003294) usually ships 8-21 days
