# | Part | Description | Price | Req | Notes | Availability |
1 |
183-2593
|
Squeegee strap rear |
$35.48
|
1 |
|
usually ships 9-20 days |
2a |
183-4619
|
Squeegee blade rear gum rubber |
$32.01
|
1 |
(from SN 10003598) |
ships same day |
2b |
183-4619
|
Squeegee blade rear gum rubber |
$32.01
|
1 |
(up to SN 10003597) |
ships same day |
3 |
183-2305
|
Wing nut |
$4.24
|
1 |
|
usually ships 9-20 days |
4 |
183-2594
|
Squeegee coupling |
$47.42
|
1 |
|
ships same day |
5 |
183-2595
|
Squeegee body |
$43.26
|
1 |
|
usually ships 9-20 days |
6 |
183-2596
|
Screw M5 x 12mm |
$1.77
|
1 |
|
usually ships 9-20 days |
7 |
183-2597
|
Screw M6 x 20mm |
$1.23
|
2 |
|
usually ships 9-20 days |
8 |
183-2457
|
Washer INOX |
$0.86
|
2 |
|
usually ships 9-20 days |
9 |
183-2598
|
Bushing |
$7.30
|
2 |
|
ships same day |
10 |
183-4714
|
Wheel (black) |
$10.50
|
4 |
|
ships same day |
11 |
183-2599
|
Right hand wheel support |
$13.64
|
1 |
|
usually ships 9-20 days |
12 |
183-8271
|
Nut INOX |
$1.23
|
2 |
|
usually ships 9-20 days |
13 |
183-8214
|
Nut |
$5.16
|
1 |
|
ships same day |
14 |
183-2600
|
Screw M6 x 40mm |
$1.23
|
2 |
|
usually ships 9-20 days |
15 |
183-2601
|
Inner rubber holder support |
$35.26
|
1 |
|
usually ships 9-20 days |
16 |
183-4620
|
Squeegee blade front gum rubber |
$24.04
|
1 |
|
ships same day |
17 |
183-2602
|
Screw M6 x 35mm |
$1.23
|
2 |
|
usually ships 9-20 days |
18 |
183-2603
|
Left hand wheel support |
$13.64
|
1 |
|
usually ships 9-20 days |
19 |
183-8524
|
Screw M6 x 25 |
$1.23
|
2 |
|
usually ships 9-20 days |
20 |
183-2604
|
Rear coupler |
$21.61
|
1 |
|
usually ships 9-20 days |
21 |
183-2605
|
Closing with screw M4 x 35mm |
$65.03
|
1 |
|
usually ships 9-20 days |
22a |
183-2606
|
Squeegee assembly (OBSOLETE) |
Call for price
|
1 |
(from SN 10003598) |
usually ships 9-20 days |
22b |
183-4781
|
Squeegee assembly |
$382.95
|
1 |
(up to SN 10003597) |
usually ships 9-20 days |
23 |
183-2607
|
Screw M2.5 x 6mm |
$1.23
|
1 |
|
usually ships 9-20 days |
24 |
183-8214
|
Nut |
$5.16
|
1 |
|
ships same day |
