MARATHON 2000 Lower Tank Assembly

#PartDescriptionPriceReqNotesAvailability
1 999-1240 Screw 1/4-20 x 3/4 oval head phillips stainless steel $1.45 1 usually ships 12-18 days
2 999-0051 Washer #6 medium split lock $0.99 6 ships same day
3 999-0060 Washer 1/4 split lock plain finish $0.99 7 ships same day
4 999-0553 Washer 5/16 medium split lock stainless steel $0.99 10 ships same day
5 183-4550 Washer #10 H/S lock $1.54 1 usually ships 15-28 days
6 999-0147 Screw 6-32 x 3/8 round head slotted zinc plated $0.99 6 ships same day
7 999-1232 Screw 5/16-18 x 3/4 hex head stainless steel $0.99 8 ships same day
8 999-0152 Nut 1/4-20 nylon insert lock zinc plated $0.99 4 ships same day
9 183-2218 Washer plain $1.54 2 usually ships 1-5 days
10 999-0016 Washer 1/4 flat plain finish $0.99 2 ships same day
11 183-4561 3/4 Inch retianing ring $1.43 4 usually ships 1-5 days
12 999-0038 Bolt 3/8-16 x 1 hex head grade 5 zinc plated $1.87 4 ships same day
13 183-4414 Washer 3/8 H/S $1.54 5 usually ships 1-5 days
14 999-0032 Washer 3/8 USS flat plain finish $2.42 15 ships same day
15 183-0748 Extension retaining ring 3/8 $7.13 2 usually ships 1-5 days
16 183-4560 Washer 25/32 $4.40 8 usually ships 1-5 days
17 999-0016 Washer 1/4 flat plain finish $0.99 1 ships same day
18 999-0399 Screw 5/16-18 x 3/4 pan head phillips zinc plated $0.99 3 ships same day
19 183-0702 Screw 3/8-16 x 3/8 socket head shoulder $11.12 1 usually ships 15-28 days
20 999-1099 Bolt 1/4-20 x 3/4 hex head stainless steel $0.99 2 ships same day
21 999-1098 Nut 1/4-20 finished hex stainless steel $0.99 2 ships same day
22 189-2998 Screw 3/8-16 x 3/4 hex end cap $0.32 4 usually ships 1-5 days
23 183-2181 Screw truss head phillips $1.54 9 usually ships 15-28 days
24 183-2220 Square key $5.69 2 usually ships 1-5 days
25a 183-4316 Handle grip $17.86 1 usually ships 1-5 days
25b 183-4316 Handle grip $17.86 1 usually ships 1-5 days
26 183-0512 Clip $5.47 3 usually ships 15-28 days
28 183-9004 Swivel caster $144.22 2 usually ships 1-5 days
29 183-8146 Washer 1/4 plain $0.80 5 ships same day
30 183-0862 Plain washer $1.54 3 usually ships 15-28 days
31 183-4554 Hose adapter tube nozzle $32.76 1 usually ships 1-5 days
32 999-1198 Screw 3/8-16 x 3/4 truss head slotted stainless steel $2.24 5 ships same day
33 999-0509 Screw 1/4-20 x 3/8 pan head phillips zinc plated $0.99 4 ships same day
34 999-0211 Nut 5/16-18 hex nylon insert lock zinc plated $0.99 1 ships same day
35 183-4551 Drain hose hanger $47.21 1 usually ships 1-5 days
36 183-4568 Bottom tank $2,048.02 1 usually ships 1-5 days
37 183-4570 Bottom tank inlet cover $157.11 1 usually ships 15-28 days
38 183-4563 Pump cover $169.29 1 usually ships 1-5 days
39 183-4571 Hinge $49.23 1 usually ships 1-5 days
40 183-4553 Carpet extractor nozzle $217.15 1 usually ships 15-28 days
41 183-4559 Bottom tank bracket $292.26 1 usually ships 1-5 days
42 183-4557 Vacuum nozzle bracket $195.09 1 usually ships 1-5 days
43 183-4562 Transaxle bracket $40.02 2 usually ships 1-5 days
44 183-4315 Handle $120.88 1 usually ships 15-28 days
45 183-0021 Bumper wheel $15.39 2 ships same day
46 183-4555 Brush attatchment rod $54.78 1 usually ships 1-5 days
47 183-9010 Handle bracket $51.43 1 usually ships 15-28 days
48 183-4314 Bar $84.39 1 usually ships 1-5 days
49 183-4564 Bumper wheel spacer (Obsolete) $6.34 2 usually ships 1-5 days
50 183-4566 Bumper wheel bushing (Obsolete) $7.47 2 usually ships 1-5 days
51 183-4317 Ball joints $44.30 2 usually ships 1-5 days
52 183-4552 Bracket adjusting screw $40.07 1 usually ships 1-5 days
53 183-4556 Attachment rod spacer $6.58 4 usually ships 1-5 days
54 999-1239 Screw 3/8-16 x 1 5/8 hex head stainless steel $6.56 2 usually ships 1-5 days
55 999-0380 Screw 3/8-16 x 1/2 cup point socket set alloy plain finish $0.99 6 ships same day
56 999-0567 Screw 1/4-20 x 5/8 pan head phillips stainless steel $0.99 4 ships same day
57 999-1238 Nut 5/16-24 hex stainless steel $0.99 2 ships same day
59 183-4573 Spray wand assembly $298.27 1 usually ships 1-5 days
60a 183-2224 Front weight $229.97 1 usually ships 1-5 days
60b 183-2224 Front weight $229.97 1 usually ships 1-5 days
61 183-2225 Bracket $51.77 1 usually ships 1-5 days
62 183-2226 115V transaxle $2,141.10 1 usually ships 1-5 days
63 183-2227 Wheel $178.26 2 usually ships 1-5 days
64 216-0075 Hose clamp $3.96 1 usually ships 1-5 days
N/S 999-0571 Screw 10-24 x 3/8 pan head phillips stainless steel $0.99 1 ships same day
N/S 183-4572 Steel supported black hose with cuffs $29.83 1 usually ships 1-5 days
