| # | Part | Description |
Req | Notes | Availability |
|---|
3 |
183-0740
|
1HP brush motor |
1 |
|
|
4 |
183-0741
|
24 inch Brush cover |
1 |
|
|
5 |
183-0062
|
Brush retainer plate (OBSOLETE) |
1 |
|
|
6 |
183-0742
|
Screw 1/4-20 x 1/4 socket set black oxide |
1 |
|
|
7 |
183-0064
|
Brush retainer plate (OBSOLETE) |
1 |
|
|
8 |
183-0064
|
Brush retainer plate (OBSOLETE) |
2 |
|
|
9 |
183-0066
|
Clutch retaining ring |
1 |
|
|
10 |
183-0063
|
Screw |
1 |
|
|
11 |
183-4220
|
Extension spring |
1 |
|
|
12 |
183-0744
|
20 inch Bumper strap |
1 |
|
|
13 |
183-0002
|
Keeper |
2 |
|
|
14 |
183-0746
|
20 inch Brush cover bumper (OBSOLETE) |
1 |
|
|
16 |
183-0716
|
Flanged bearing 3/8 bronze |
2 |
|
|
17 |
999-1073
|
Screw 3/8-16 x 5/8 hex head grade 5 zinc plated |
4 |
|
|
18 |
183-0749
|
Bearing retaining plate (OBSOLETE) |
1 |
|
|
20 |
999-1075
|
Screw 8-32 x 3/4 round head slotted stainless steel |
2 |
|
|
21 |
183-0022
|
Washer wave |
4 |
|
|
22 |
183-0021
|
Bumper wheel |
2 |
|
|
23 |
999-0032
|
Washer 3/8 USS flat plain finish |
6 |
|
|
24 |
999-0350
|
Bolt 3/8-16 x 1 1/2 hex head grade 5 zinc plated |
2 |
|
|
25 |
183-0750
|
Pin (Obsolete) |
1 |
|
|
26 |
183-0752
|
Compression spring |
1 |
|
|
28 |
999-0077
|
Nut 8-32 k-lock zinc plated |
2 |
|
|
29 |
183-0751
|
Cap |
1 |
|
|
31 |
183-1237
|
Positive labelwire marker |
1 |
|
|
N/S |
996-1409
|
19 inch Pad driver |
1 |
|
|
