# | Part | Description | Price | Req | Notes | Availability |
1 |
183-7691
|
Plastic bearing mount |
$5.50
|
4 |
|
usually ships 8-21 days |
2 |
183-6094
|
Control panel |
$307.99
|
1 |
|
usually ships 1-5 days |
3 |
183-7702
|
Snap switch with roller |
$49.94
|
3 |
|
usually ships 8-21 days |
4 |
183-6095
|
Battery meter |
$239.23
|
1 |
|
usually ships 1-5 days |
5 |
183-7706
|
Squeegee lift lever |
$178.15
|
1 |
|
usually ships 8-21 days |
6 |
183-7708
|
Tie rod end |
$78.39
|
1 |
|
usually ships 8-21 days |
7 |
183-7700
|
30amp circuit breaker |
$40.33
|
1 |
|
usually ships 8-21 days |
8 |
183-7692
|
Bail |
$34.13
|
1 |
|
usually ships 8-21 days |
9a |
183-7698
|
Key switch |
$92.20
|
1 |
(includes 9b) |
usually ships 8-21 days |
9b |
183-7699
|
Replacement key |
$43.58
|
1 |
|
usually ships 8-21 days |
10 |
183-7707
|
Knob |
$16.41
|
1 |
|
usually ships 8-21 days |
11 |
183-7695
|
Extension spring |
$41.62
|
2 |
|
usually ships 8-21 days |
12 |
183-7675
|
Washer |
Call for price
|
4 |
|
usually ships 8-21 days |
13 |
183-7693
|
Nylock nut |
Call for price
|
6 |
|
usually ships 8-21 days |
14 |
183-7696
|
Screw #10-32 x 1-1/2 inch |
Call for price
|
1 |
|
usually ships 8-21 days |
15 |
183-7681
|
Nylock nut |
$5.08
|
4 |
|
usually ships 8-21 days |
16 |
183-7680
|
Nylock nut |
Call for price
|
2 |
|
usually ships 8-21 days |
17 |
999-1032
|
Screw 1/4-20 x 5/8 hex head stainless steel |
$0.99
|
4 |
|
ships same day |
18 |
183-7703
|
Screw #4-40 x 7/8 inch |
Call for price
|
6 |
|
usually ships 8-21 days |
19 |
183-7704
|
Washer |
Call for price
|
6 |
|
usually ships 8-21 days |
20 |
183-7705
|
Nylock nut |
Call for price
|
6 |
|
usually ships 8-21 days |
21 |
183-7710
|
Nylock nut |
Call for price
|
1 |
|
usually ships 8-21 days |
22 |
183-6096
|
Momentary switch |
$49.54
|
1 |
|
usually ships 1-5 days |
26 |
183-6097
|
Potentiometer Assembly |
$181.27
|
1 |
|
usually ships 1-5 days |
27 |
183-7715
|
Cable lift clevis |
$58.34
|
1 |
|
usually ships 8-21 days |
28 |
183-7709
|
Nut |
Call for price
|
1 |
|
usually ships 8-21 days |
29 |
183-7685
|
Charger harness |
$146.80
|
1 |
|
usually ships 8-21 days |
30 |
183-7714
|
Washer |
Call for price
|
2 |
|
usually ships 8-21 days |
31 |
183-6099
|
Knob |
$63.14
|
1 |
|
usually ships 1-5 days |
32 |
183-7694
|
Screw .1/4 x 1-3/4 inch |
Call for price
|
4 |
|
usually ships 8-21 days |
33 |
183-7716
|
Screw 1/4-20 x 1 inch |
$29.71
|
2 |
|
usually ships 8-21 days |
34 |
183-7682
|
Screw #6-32 x 1 inch |
Call for price
|
2 |
|
usually ships 8-21 days |
35 |
183-7697
|
Nut |
Call for price
|
1 |
|
usually ships 8-21 days |
36 |
183-7713
|
Bracket |
$26.05
|
1 |
|
usually ships 8-21 days |
37 |
183-6100
|
Traction drive control decal |
$28.78
|
1 |
|
usually ships 1-5 days |
39 |
183-7719
|
External star washer |
Call for price
|
4 |
|
usually ships 8-21 days |
40 |
183-7720
|
Mounting plate |
$41.83
|
1 |
|
usually ships 8-21 days |
43 |
183-7746
|
Screw 1/32 x 1 inch |
Call for price
|
1 |
|
usually ships 8-21 days |
44 |
183-7772
|
Washer |
Call for price
|
2 |
|
usually ships 8-21 days |
N/S |
183-6098
|
Hour meter with reset |
$129.42
|
1 |
|
usually ships 1-5 days |
N/S |
183-6101
|
Power harness |
$398.59
|
1 |
|
usually ships 1-5 days |
N/S |
183-6102
|
Signal harness |
$523.59
|
1 |
|
usually ships 1-5 days |
