| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
183-8424
|
Nut |
3 |
|
|
2 |
183-2488
|
Conical washer |
1 |
|
|
3 |
183-7620
|
Spacer (OBSOLETE) |
1 |
|
|
4 |
183-7621
|
Arm adjuster (OBSOLETE) |
1 |
|
|
5 |
183-8411
|
Nut |
1 |
|
|
6 |
183-7618
|
Arms stud bolts (OBSOLETE) |
2 |
|
|
7 |
183-8429
|
Compression spring |
1 |
|
|
8 |
183-5115
|
Arm (OBSOLETE) |
1 |
|
|
9 |
183-8424
|
Nut |
2 |
|
|
10 |
183-9123
|
Screw M10 x 35mm |
1 |
|
|
11 |
183-9343
|
Nut |
1 |
|
|
12 |
183-9123
|
Screw M10 x 35mm |
1 |
|
|
13 |
183-9210
|
Black nut cover |
1 |
|
|
14 |
183-2504
|
Washer |
2 |
|
|
15 |
183-7619
|
Bushing (OBSOLETE) |
1 |
|
|
16 |
183-5116
|
Brush base arm |
1 |
|
|
17 |
183-9344
|
Bushing |
2 |
|
|
18 |
183-8312
|
Washer |
1 |
|
|
19 |
183-9345
|
Screw M12-1.5 x 30mm |
1 |
|
|
20 |
183-9324
|
Washer |
4 |
|
|
21 |
183-9346
|
Pin |
1 |
|
|
22 |
183-9120
|
Cotter pin |
4 |
|
|
23 |
183-9347
|
Support plate |
1 |
|
|
24 |
183-9350
|
Actuator microswitch |
2 |
|
|
25 |
183-5117
|
Brush actuator motor |
1 |
|
|
26 |
183-5118
|
Pin (OBSOLETE) |
1 |
|
|
27 |
183-5119
|
Bushing (OBSOLETE) |
1 |
|
|
28 |
183-5120
|
Rocker arm (OBSOLETE) |
1 |
|
|
31 |
183-8300
|
Screw M8 x 25 |
1 |
|
|
32 |
183-9343
|
Nut |
1 |
|
|
33 |
183-5121
|
Traction spring (OBSOLETE) |
1 |
|
|
34 |
183-5122
|
Threaded tie rod (OBSOLETE) |
1 |
|
|
35 |
183-9324
|
Washer |
2 |
|
|
36 |
183-5123
|
Spacer (OBSOLETE) |
1 |
|
|
37 |
183-9348
|
Nut |
1 |
|
|
38 |
183-9349
|
Handwheel |
1 |
|
|
39 |
183-2465
|
Cap |
1 |
|
|
