| # | Part | Description |
Req | Notes | Availability |
|---|
002 |
183-0206
|
Screw |
6 |
|
|
003 |
183-0353
|
Counter holder |
1 |
|
|
004 |
183-0354
|
Plate |
2 |
|
|
007 |
183-0355
|
Cable connector (obsolete) |
1 |
|
|
008 |
183-0356
|
Insulating hose |
1 |
|
|
009b |
183-0358
|
High/low grout brush - CYLINDRICAL (orange) |
2 |
|
|
009c |
183-0359
|
Extra heavy grit scrubbing brush (gray) |
2 |
|
|
009d |
183-0360
|
Soft scrub brush black |
2 |
|
|
009e |
183-0361
|
Standard brush roll |
2 |
|
|
009f |
183-0362
|
Red brush roll |
2 |
|
|
009g |
183-0363
|
Grey brush roll |
2 |
|
|
009h |
183-0364
|
Black brush roll |
2 |
|
|
010a |
183-0365
|
Plate |
1 |
|
|
010b |
183-0366
|
Plate |
1 |
|
|
011a |
183-0367
|
Strip |
1 |
|
|
011b |
183-0368
|
Strip |
1 |
|
|
012 |
183-0281
|
Screw |
14 |
|
|
013a |
183-0369
|
Spring |
2 |
|
|
013b |
183-0370
|
Spring (Obsolete) |
2 |
|
|
014 |
183-0371
|
Drive shaft |
2 |
|
|
015 |
183-0372
|
Washer |
2 |
|
|
016 |
183-0373
|
Safety ring |
3 |
|
|
017 |
183-0374
|
Sleeve |
2 |
|
|
018 |
183-0375
|
Ball bearing |
6 |
|
|
019a |
183-0376
|
Pulley |
1 |
|
|
019b |
183-0377
|
Pulley (Obsolete) |
1 |
|
|
020 |
183-0378
|
Plate |
1 |
|
|
021 |
183-0379
|
Washer |
6 |
|
|
022 |
183-0093
|
Screw M6-1 x 16mm |
10 |
|
|
023a |
183-0380
|
Screw (Obsolete) |
1 |
|
|
023b |
183-0381
|
Screw |
1 |
|
|
024 |
183-7523
|
Belt |
1 |
|
|
025a |
183-0382
|
Sleeve |
1 |
|
|
025b |
183-0383
|
Sleeve (Obsolete) |
1 |
|
|
026 |
183-0384
|
Roller |
1 |
|
|
027a |
183-0341
|
Hex nut |
1 |
|
|
027b |
183-0385
|
Hex nut (Obsolete) |
1 |
|
|
028 |
183-0099
|
Washer |
3 |
|
|
029a |
183-0386
|
Pulley |
2 |
|
|
029b |
183-0387
|
Pulley (Obsolete) |
2 |
|
|
030 |
183-0388
|
Spring plate |
2 |
|
|
031a |
183-0389
|
Cover plate |
1 |
|
|
031b |
183-0390
|
Cover plate (Obsolete) |
1 |
|
|
033 |
183-0391
|
Motor |
1 |
|
|
034 |
183-0392
|
Carbon brush (pkg of 2) |
1 |
|
|
035 |
183-0393
|
Spring |
1 |
|
|
036 |
183-0394
|
Quick fastener (OBSOLETE) |
2 |
|
|
037 |
183-0304
|
Hex nut |
1 |
|
|
038 |
183-0395
|
Washer |
1 |
|
|
039 |
183-0202
|
Screw |
1 |
|
|
040 |
183-0396
|
Foot stand |
1 |
|
|
041 |
183-0397
|
Stand |
1 |
|
|
042 |
183-0398
|
Axle (OBSOLETE) |
1 |
|
|
043 |
183-0348
|
Roller |
1 |
|
|
044 |
183-0399
|
Retainer clip |
2 |
|
|
045 |
183-0400
|
Axle |
1 |
|
|
046 |
183-0401
|
Pipe |
2 |
|
|
047 |
183-0402
|
Pipe connection |
1 |
|
|
048 |
999-9100
|
Washer M5 flat stainless steel |
4 |
|
|
049 |
183-0404
|
Bracket (Obsolete) |
1 |
|
|
050 |
183-0405
|
Hex nut |
3 |
|
|
051 |
183-0406
|
Hex screw |
1 |
|
|
052a |
183-0407
|
Brush housing (Obsolete) |
1 |
|
|
052b |
183-0408
|
Brush housing |
1 |
|
|
053 |
183-0409
|
Pipe |
2 |
|
|
054 |
183-0216
|
Washer |
1 |
|
|
055a |
183-0410
|
Plate (Obsolete) |
1 |
|
|
055b |
183-0411
|
Plate |
1 |
|
|
057 |
183-0412
|
Sleeve (Obsolete) |
1 |
|
|
059 |
183-0413
|
Washer |
4 |
|
|
060 |
183-0414
|
Screw (Obsolete) |
4 |
|
|
061 |
183-0415
|
Pin (threaded) |
2 |
|
|
062 |
273-3611
|
Wing nut |
2 |
|
|
