| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
182-0703
|
Cyclone |
|
|
|
002 |
182-0704
|
Top hinged support |
|
|
|
003 |
182-0705
|
Dust cup handle |
|
|
|
004 |
182-0706
|
Plenum cover |
|
|
|
005 |
182-0707
|
Front handle bracket |
|
|
|
006 |
182-0708
|
Rear handle bracket |
|
|
|
007 |
182-0709
|
Handle cap |
|
|
|
008 |
182-0710
|
Dust cup filter |
|
|
|
009 |
182-0711
|
Latch |
|
|
|
010 |
182-0712
|
Plenum cover gasket |
|
|
|
011 |
182-0713
|
Gasket |
|
|
|
012 |
182-0583
|
Screw (OBSOLETE) |
|
|
|
013 |
182-0714
|
Screw package |
|
|
|
014 |
182-0589
|
Compression spring |
|
|
|
015 |
182-0715
|
Dust cup assembly - cartoned |
|
|
|
016 |
182-0716
|
Top cover - packaged |
|
|
|
017 |
182-0717
|
Cyclone assembly - cartoned |
|
|
|
018 |
182-0718
|
Top hinged support gasket |
|
|
|
019 |
182-0674
|
Filter cage |
|
|
|
020 |
182-0719
|
Plenum handle |
|
|
|
021 |
182-0720
|
Spring support cover |
|
|
|
022 |
182-0721
|
Handle and cap assembly (OBSOLETE) |
|
|
|
