| # | Part | Description |
Req | Notes | Availability |
|---|
002 |
181-1148
|
Ball bearing (OBSOLETE) |
1 |
|
|
003 |
N/A
|
Not available |
1 |
(Center switch) |
|
004 |
N/A
|
Not available |
1 |
115v actuator motor (product is obsolete) |
|
005a |
N/A
|
Not available |
1 |
(Capacitor) |
|
005b |
N/A
|
Not available |
1 |
(Capacitor) |
|
006 |
272-0869
|
Coupling support ring (OBSOLETE) |
1 |
|
|
007 |
N/A
|
Not available |
2 |
Idler shaft (product is obsolete) |
|
008 |
N/A
|
Not available |
4 |
(Needle bearing) |
|
009 |
181-1154
|
Ball bearing (OBSOLETE) |
1 |
|
|
010 |
N/A
|
Not available |
2 |
Gear idler (product is obsolete) |
|
011 |
181-1152
|
Ball bearing (OBSOLETE) |
3 |
|
|
012a |
N/A
|
Not available |
1 |
(Pinion) |
|
012b |
N/A
|
Not available |
1 |
(Pinion) |
|
013a |
170-0694
|
Odum coupling |
1 |
|
|
014 |
N/A
|
Not available |
1 |
(Ball bearing) |
|
015 |
N/A
|
Not available |
6 |
Screw 10-32 x 1 socket head cap (product is obsolete) |
|
016a |
N/A
|
Not available |
1 |
Gear unit assemly 1,2 idler (product is obsolete) |
|
016b |
N/A
|
Not available |
1 |
Gear unit assembly 1,3 idler (product is obsolete) |
|
