| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
172-2370
|
Right tank axle |
1 |
|
|
002 |
272-1923
|
Screw M6-1 x 12mm hex head |
4 |
|
|
003 |
172-2371
|
Chassis (OBSOLETE) |
1 |
|
|
004 |
172-2372
|
Nut hex |
1 |
|
|
005 |
272-2712
|
Caster wheel kit |
1 |
(includes 004) |
|
007 |
181-0914
|
Spacer |
1 |
|
|
008 |
172-2374
|
Tank closure kit (OBSOLETE) |
1 |
(includes 007 and 009) |
|
009 |
N/A
|
Not available |
1 |
|
|
010 |
172-2375
|
Left tank axle (OBSOLETE) |
1 |
|
|
011 |
272-8091
|
Allen wrench |
1 |
|
|
012 |
272-8093
|
Cable guide |
1 |
|
|
013 |
172-2376
|
Reinforced seal (OBSOLETE) |
1 |
|
|
014 |
172-2377
|
Seal (OBSOLETE) |
1 |
|
|
027 |
999-1324
|
Screw M8-1.25 x 20mm flat head stainless steel |
2 |
|
|
028 |
272-8089
|
Spacer |
2 |
|
|
029 |
172-2368
|
Wheel with hub |
2 |
|
|
030 |
N/A
|
Not available |
2 |
(Wheel stud) |
|
031 |
272-1914
|
Screw M6-1 x 16mm hex head |
4 |
|
|
