| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
275-2615
|
Telemetry control box assembly kit |
1 |
|
|
2 |
999-0502
|
Bolt M6-1 x 20mm hex head full thread zinc |
4 |
|
|
3 |
999-0469
|
Nut M6-1 nylon insert lock zinc plated |
4 |
|
|
4 |
275-2616
|
Module plate (Tennant Industrial) |
1 |
|
|
5 |
275-2617
|
400amp shunt (Tennant Industrial) |
1 |
|
|
6 |
175-2895
|
Screw M5-0.8 x 20mm pan head |
2 |
|
|
7 |
999-0201
|
Washer 3/8 internal star lock |
2 |
|
|
8 |
175-2894
|
Nut M5-.8 hex nylon locking |
4 |
|
|
9 |
275-7897
|
Antenna |
1 |
|
|
10 |
175-0988
|
P clamp |
2 |
|
|
11 |
275-2618
|
Screw M5-1 x 16mm hex head black (Tennant Industrial) |
2 |
|
|
12 |
275-2619
|
Washer flat black (Tennant Industrial) |
2 |
|
|
13a |
275-2620
|
Electrical harness (Tennant Industrial) |
1 |
(includes 13b) |
|
13b |
275-7904
|
Fuse (Tennant Industrial) |
1 |
|
|
14 |
275-2621
|
Cable (black) (Tennant Industrial) |
1 |
|
|
15 |
175-2162
|
Nylon wire tie |
6 |
|
|
16 |
175-3168
|
P clamp |
1 |
|
|
17 |
275-7899
|
Telemetry decal |
1 |
|
|
