| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
175-0570
|
KNOB, 1.12D 3.88L M08 X 1.25, PLSTC[TPR] (Tennant Industria |
1 |
|
|
2 |
175-0571
|
Pin (Tennant Industrial) (OBSOLETE) |
1 |
|
|
3 |
175-0572
|
BUSHING, FLNG, 0.50B 0.62D 0.25L (Tennant Industrial) |
1 |
|
|
4 |
175-0573
|
SPRING, TORS (Tennant Industrial) |
1 |
|
|
5 |
175-0574
|
Bolt 6mm-1 x 35 hex head |
1 |
|
|
6 |
999-0469
|
Nut M6-1 nylon insert lock zinc plated |
1 |
|
|
7a |
275-7953
|
Steering wheel (Tennant Industrial) |
1 |
(includes 7b) |
|
7b |
275-2812
|
COVER, STEERING WHEEL (Tennant Industrial) |
1 |
|
|
8 |
275-2813
|
NUT, HEX, JAM, M20 X 1.5 (Tennant Industrial) |
1 |
|
|
9a |
275-9082
|
STEERING KIT, POWER, CI [7300/8300] (Tennant Industrial) |
1 |
(before SN 003714) (includes 9b) |
|
9b |
275-8318
|
VR, CAP, TUBE (Tennant Industrial) |
1 |
(before SN 003714) |
|
10 |
275-9082
|
STEERING KIT, POWER, CI [7300/8300] (Tennant Industrial) |
1 |
(before SN 003714) |
|
11 |
275-0302
|
Screw M10-1.5 x 16 hex head |
4 |
(before SN 003714) |
|
12 |
175-8103
|
FITTING, HYD, STR, JM06/OM06 (Tennant Industrial) |
3 |
|
|
13 |
175-6968
|
FITTING, HYD, STR, JM04/OM06 (Tennant Industrial) |
2 |
|
|
14 |
275-7954
|
Steering bracket weldment (Tennant Industrial) |
1 |
|
|
15 |
275-2808
|
BEARING, FLNG, 2HOLE, 0.50B (Tennant Industrial) |
2 |
|
|
16 |
999-0507
|
Bolt M6-1 x 16mm hex head full thread plain finish |
4 |
|
|
17 |
275-8310
|
MOTOR, HYD, GEAR, INT (Tennant Industrial) |
1 |
|
|
18 |
275-8311
|
FITTING, HYD, STR, JM04/OM10 (Tennant Industrial) |
2 |
|
|
19 |
275-8431
|
SCREW, SOC, M12 X 1.75 X 45, 12.9 (Tennant Industrial) |
2 |
|
|
20 |
999-0114
|
Washer 1/2 SAE flat |
4 |
|
|
21 |
275-8313
|
BUSHING, TLB (Tennant Industrial) |
1 |
|
|
22 |
275-8314
|
SPROCKET, 40, 24TOOTH, TLB, 1.87B 0.81W (Tennant Industrial |
1 |
|
|
23 |
275-8315
|
CHAIN, RLR, 40 X 109 PITCHES (Tennant Industrial) |
1 |
|
|
24 |
999-0519
|
Nut M12-1.75 nylon insert lock stainless steel |
2 |
|
|
25 |
175-0583
|
LINK, CHAIN, RLR, 40 (Tennant Industrial) |
1 |
|
|
26 |
275-8312
|
HANDLE WLDT, STEERING, TILT (Tennant Industrial) |
1 |
|
|
27 |
275-8316
|
MOLDING, TRIM, PVC, .18-.31 12.0L (Tennant Industrial) |
1 |
|
|
28a |
275-8317
|
COLUMN, STEERING, 14.0L .81D 36TOOTH (Tennant Industrial) |
1 |
(after SN 003713 and before SN 007245) (includes 28c) |
|
28b |
275-7955
|
Steering column (Tennant Industrial) |
1 |
(after SN 007244) (includes 28c) |
|
28c |
275-8318
|
VR, CAP, TUBE (Tennant Industrial) |
1 |
|
|
29 |
275-8319
|
STEER-CONTROL, HYD05, 05.0 2030 (Tennant Industrial) |
1 |
(after SN 003713) |
|
30 |
999-0507
|
Bolt M6-1 x 16mm hex head full thread plain finish |
4 |
(after SN 003713) |
|
