| # | Part | Description | Price | Req | Notes | Availability |
|---|
001a |
275-9051
|
FRAME WLDT, MAIN [7300/8300] (Tennant Industrial) |
$5,153.62
|
1 |
(before SN 007000) |
usually ships 1-5 days |
001b |
175-0521
|
Main weldment frame (gray) (Tennant Industrial) (OBSOLETE) |
$4,571.50
|
1 |
(after SN 006999) |
usually ships 1-5 days |
002a |
175-0522
|
PLATE, COVER (Tennant Industrial) |
$370.41
|
1 |
(before SN 007000) |
usually ships 1-5 days |
002b |
275-2451
|
Cover plate (iron gray) (Tennant Industrial) |
$23.05
|
1 |
(after SN 006999) |
usually ships 1-5 days |
003 |
175-0523
|
RIVET, PLSTC, .250D X 0.75 (Tennant Industrial) |
$4.84
|
24 |
|
usually ships 1-5 days |
004a |
175-0533
|
CHANNEL WLDT, STEERING (Tennant Industrial) (OBSOLETE) |
$172.38
|
1 |
(before SN 007000) |
usually ships 1-5 days |
004b |
275-2453
|
Channel weldment (iron gray) (Tennant Industrial) |
$308.78
|
1 |
(after SN 006999) |
usually ships 1-5 days |
005 |
999-1133
|
Bolt M8-1.25 x 20mm hex head full thread plain |
$0.99
|
5 |
|
ships same day |
006 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
$0.99
|
5 |
|
ships same day |
007 |
999-0024
|
Washer 5/16 flat stainless steel |
$1.34
|
31 |
|
ships same day |
008 |
175-0534
|
T3026 WLDT, FLOOR (Tennant Industrial) (OBSOLETE) |
$604.63
|
1 |
(before SN 003798) |
usually ships 1-5 days |
009 |
999-0783
|
Screw M8-1.25 x 16mm hex head |
$0.99
|
12 |
|
ships same day |
010a |
175-0535
|
PLATE, FLOOR, UPPER (Tennant Industrial) |
$190.38
|
1 |
(before SN 007000) |
usually ships 1-5 days |
010b |
275-2454
|
Upper floor plate (iron gray) (Tennant Industrial) |
$81.33
|
1 |
(after SN 006999) |
usually ships 1-5 days |
011 |
175-3168
|
P clamp |
$3.60
|
1 |
|
usually ships 5-16 days |
012 |
999-0665
|
Nut M8-1.25 flange lock |
$0.99
|
2 |
|
ships same day |
013 |
175-3160
|
Horn |
$96.80
|
1 |
|
usually ships 5-16 days |
014 |
175-0536
|
Bolt M6-1 x 20mm hex head thread forming |
$3.00
|
1 |
|
ships same day |
015 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
1 |
|
ships same day |
016 |
999-0502
|
Bolt M6-1 x 20mm hex head full thread zinc |
$0.99
|
2 |
|
ships same day |
017a |
275-8285
|
FRAME, SWPR [8300] (Tennant Industrial) |
$5,170.32
|
1 |
(before SN 007000) |
usually ships 1-5 days |
017b |
275-7940
|
Iron frame (Tennant Industrial) (OBSOLETE) |
$2,531.50
|
1 |
(after SN 006999) |
usually ships 1-5 days |
018a |
275-8286
|
BRACKET, MTG (Tennant Industrial) (OBSOLETE) |
$14.75
|
2 |
(before SN 007000) |
usually ships 1-5 days |
018b |
275-7941
|
Iron mounting bracket (Tennant Industrial) |
$24.05
|
2 |
(after SN 006999) |
usually ships 1-5 days |
019 |
999-0187
|
Washer 1/2 flat plain finish |
$0.99
|
12 |
|
ships same day |
020 |
175-0615
|
Bolt M12-1.75 x 25mm hex head |
$3.60
|
12 |
|
usually ships 5-16 days |
021a |
275-8287
|
BRACKET, MTG (Tennant Industrial) |
$95.52
|
2 |
(before SN 007000) |
usually ships 1-5 days |
021b |
275-7942
|
Iron mounting bracket (Tennant Industrial) |
$35.24
|
2 |
(after SN 006999) |
usually ships 1-5 days |
022 |
999-1133
|
Bolt M8-1.25 x 20mm hex head full thread plain |
$0.99
|
4 |
|
ships same day |
023 |
999-0581
|
Bolt M8-1.25 x 25mm hex head full thread zinc |
$0.99
|
6 |
|
ships same day |
024 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
$0.99
|
4 |
|
ships same day |
025a |
675-0389
|
TAILLIGHT, 12VDC, 3.6 X 1.9, RWK 1075205 (Tennant Industrial |
$176.19
|
2 |
(includes 25b and 25c) |
usually ships 5-16 days |
025b |
175-0526
|
LAMP, 12VDC, 0.3A, 02CP [#194] (Tennant Industrial) |
$12.36
|
1 |
|
usually ships 1-5 days |
025c |
175-0527
|
LAMPHOLDER (Tennant Industrial) |
$33.73
|
1 |
|
usually ships 1-5 days |
026 |
999-0460
|
Nut 10-32 hex |
$0.99
|
4 |
|
ships same day |
027 |
999-0089
|
Washer #10 internal star lock zinc plated |
$0.99
|
4 |
|
ships same day |
028 |
275-8288
|
STOP (Tennant Industrial) |
$30.23
|
2 |
|
usually ships 1-5 days |
029a |
275-8289
|
BRACKET, LH (Tennant Industrial) |
$84.17
|
1 |
(before SN 007000) |
usually ships 1-5 days |
029b |
275-7943
|
Left hand iron bracket (Tennant Industrial) |
$11.52
|
1 |
(after SN 006999) |
usually ships 1-5 days |
030a |
275-8290
|
BRACKET, RH (Tennant Industrial) |
$84.17
|
1 |
(before SN 007000) |
usually ships 1-5 days |
030b |
275-7944
|
Right hand iron bracket (Tennant Industrial) |
$11.52
|
1 |
(after SN 006999) |
usually ships 1-5 days |
031a |
275-8291
|
BRACKET, LATCH, DOOR (Tennant Industrial) |
$227.96
|
2 |
(before SN 007000) |
usually ships 1-5 days |
031b |
275-7945
|
Iron door latch bracket (Tennant Industrial) |
$38.91
|
2 |
(after SN 006999) |
usually ships 1-5 days |
032a |
275-8292
|
CUP WLDT, SKID (Tennant Industrial) |
$89.35
|
1 |
(before SN 007000) |
usually ships 1-5 days |
032b |
275-7946
|
Iron stop weldment (Tennant Industrial) |
$60.12
|
1 |
(after SN 006999) |
usually ships 1-5 days |
033 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
$1.85
|
3 |
|
ships same day |
034 |
175-3168
|
P clamp |
$3.60
|
2 |
|
usually ships 5-16 days |
035 |
175-3166
|
Bolt M6-1 x 16mm hex head |
$3.60
|
2 |
|
usually ships 5-16 days |
036a |
275-8293
|
PLATE, FLOOR (Tennant Industrial) |
$231.63
|
1 |
(after 003797 and before SN 007000) |
usually ships 1-5 days |
036b |
275-9281
|
Floor plate (iron gray) (Tennant Industrial) |
$69.81
|
1 |
(after SN 006999) |
usually ships 1-5 days |
