| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
275-5076
|
24V 3 station solenoid valve |
1 |
(includes 2-4b) |
|
2 |
275-5077
|
Manifold block |
1 |
|
|
3a |
275-5078
|
24V series 3 solenoid valve |
1 |
(includes 3b) |
|
3b |
275-5079
|
Solenoid seal |
1 |
|
|
4a |
275-5080
|
24V series 6 solenoid valve |
2 |
(includes 4b) |
|
4b |
275-5081
|
Solenoid seal |
2 |
|
|
5 |
175-2613
|
Straight brass fitting |
3 |
|
|
6 |
175-6081
|
Hose clamp |
4 |
|
|
7 |
275-9714
|
Braided hose 3/8 x 5/8 x 36 inches |
1 |
|
|
8 |
275-5768
|
Plastic fitting |
1 |
|
|
9 |
175-2997
|
Elbow |
4 |
|
|
10 |
175-4814
|
Brass strainer fitting |
4 |
|
|
11 |
175-4192
|
Quick jet body |
4 |
|
|
12 |
175-4193
|
Quick jet gasket |
4 |
|
|
13 |
175-6330
|
Spray nozzle |
2 |
|
|
14 |
175-4194
|
Quick jet cap (green) |
2 |
|
|
15 |
175-4204
|
Check valve filter screen |
2 |
|
|
16 |
175-1615
|
Tee fitting |
1 |
|
|
17 |
275-4758
|
Plastic tee fitting |
1 |
|
|
18 |
275-9705
|
PVC hose 1/4 x 3 feet (gray) |
1 |
|
|
19 |
175-6170
|
Hose clamp |
2 |
|
|
20 |
175-6032
|
Hose clamp |
8 |
|
|
21 |
275-9717
|
Brass spray tip |
2 |
|
|
22 |
175-6431
|
Quick-jet cap |
2 |
|
|
