STRIVE RIDER Front Drive Wheel Assembly

#PartDescriptionPriceReqNotesAvailability
1 275-8091 Steering control assembly $1,258.84 1 usually ships 5-16 days
2 175-3200 Square keyway $3.30 1 ships same day
3 999-0499 Bolt M8-1.25 x 20mm hex head full thread stainless steel $1.85 4 ships same day
4 999-9097 Washer M8 flat stainless steel $0.99 4 ships same day
5 275-8095 Nylon strap $20.24 1 ships same day
6 275-8094 3 foot nylon sleeve $38.61 1 usually ships 5-16 days
7 175-2202 Nylon wire tie $3.30 2 ships same day
8 175-3179 P clamp $3.96 2 usually ships 5-16 days
9 175-3166 Bolt M6-1 x 16mm hex head $3.96 2 usually ships 5-16 days
10 999-0006 Washer 3/16 flat zinc plated $0.99 2 ships same day
11a 275-9654 Complete drive and gearbox assembly $4,582.38 1 (includes 12-15) usually ships 5-16 days
11b 275-8259 Solid tire (red) $749.32 1 usually ships 5-16 days
12 175-8753 Female connector $7.48 1 ships same day
13 175-8756 Male and female secondary lock $3.96 1 usually ships 5-16 days
14 275-8096 Female terminal $3.30 2 ships same day
15 275-8097 Wire seal $3.41 2 ships same day
