# | Part | Description | Price | Req | Notes | Availability |
1 |
175-9213
|
Main frame |
$1,779.14
|
1 |
|
usually ships 1-5 days |
2 |
175-9186
|
Rear skirt |
$21.89
|
1 |
|
usually ships 10-16 days |
3 |
175-9195
|
Retainer skirt plate |
$10.34
|
5 |
|
usually ships 10-16 days |
4 |
175-6631
|
Caster wheel |
$65.67
|
2 |
|
usually ships 10-16 days |
5 |
175-9214
|
Left hand main handle |
$203.28
|
1 |
|
usually ships 1-5 days |
6 |
175-9215
|
Right hand main handle |
$198.55
|
1 |
|
usually ships 1-5 days |
7 |
175-9216
|
Retainer plate |
$14.96
|
1 |
|
usually ships 1-5 days |
8 |
175-9217
|
Weldment clutch lever |
$133.21
|
1 |
|
usually ships 1-5 days |
9 |
175-9218
|
Steering handle |
$90.86
|
1 |
|
usually ships 1-5 days |
10 |
175-9220
|
Plastic knob 10-32 x 13/16 |
$9.02
|
2 |
|
usually ships 1-5 days |
11 |
175-9221
|
Threaded sleeve |
$26.84
|
2 |
|
usually ships 1-5 days |
12 |
175-7153
|
Compression spring |
$5.50
|
2 |
|
usually ships 1-5 days |
13 |
175-9222
|
PIN (Tennant Industrial) |
$42.84
|
2 |
|
usually ships 1-5 days |
14 |
175-9223
|
Nut M16 x 2 hex jam |
$4.09
|
4 |
|
usually ships 1-5 days |
15 |
175-2362
|
Washer 17 x 30 x 3 flat stainless steel |
$5.15
|
2 |
|
usually ships 10-16 days |
16 |
175-9224
|
Dirt kit shield |
$26.62
|
1 |
|
usually ships 10-16 days |
17 |
175-9225
|
Handle stop bracket |
$33.00
|
1 |
|
usually ships 1-5 days |
18 |
175-9226
|
Hole plug |
$3.43
|
2 |
|
usually ships 1-5 days |
19 |
175-9227
|
Hole plug 19/64 |
$4.09
|
4 |
|
usually ships 10-16 days |
20 |
175-9228
|
Clip |
$3.04
|
1 |
|
ships same day |
21 |
175-9229
|
Guard |
$20.02
|
1 |
|
usually ships 10-16 days |
22 |
175-9230
|
Skirt |
$66.00
|
1 |
|
usually ships 10-16 days |
23 |
999-1288
|
Washer 1/4 x 1 OD fender stainless steel |
$0.99
|
1 |
|
ships same day |
24 |
175-5924
|
Screw 10 x 5/8 hex |
$3.96
|
1 |
|
usually ships 10-16 days |
25 |
175-3378
|
Rivet 1/4 x 57/64 plastic |
$3.83
|
7 |
|
usually ships 10-16 days |
26 |
175-9231
|
Guard |
$20.02
|
1 |
|
usually ships 10-16 days |
27 |
175-9232
|
Skirt |
$66.00
|
1 |
|
usually ships 10-16 days |
28 |
999-1288
|
Washer 1/4 x 1 OD fender stainless steel |
$0.99
|
1 |
|
ships same day |
29 |
175-5924
|
Screw 10 x 5/8 hex |
$3.96
|
1 |
|
usually ships 10-16 days |
30 |
175-3378
|
Rivet 1/4 x 57/64 plastic |
$3.83
|
7 |
|
usually ships 10-16 days |
31 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
$1.85
|
2 |
|
ships same day |
32 |
999-9097
|
Washer M8 flat stainless steel |
$0.99
|
2 |
|
ships same day |
33 |
999-0248
|
Bolt M8-1.25 x 30mm hex head full thread plain finish |
$0.99
|
2 |
|
ships same day |
34 |
999-0024
|
Washer 5/16 flat stainless steel |
$1.34
|
8 |
|
ships same day |
35 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
$0.99
|
2 |
|
usually ships 12-18 days |
36 |
999-0507
|
Bolt M6-1 x 16mm hex head full thread plain finish |
$0.99
|
4 |
|
ships same day |
37 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
$0.99
|
4 |
|
ships same day |
38 |
999-0783
|
Screw M8-1.25 x 16mm hex head |
$0.99
|
4 |
|
ships same day |
39 |
175-9219
|
HANDLE KIT, ADJ, REPAIR (Tennant Industrial) |
$86.02
|
2 |
(includes 10-15) |
usually ships 1-5 days |
40 |
175-9187
|
Right hand side skirt kit |
$95.15
|
1 |
(includes 21-25) |
usually ships 10-16 days |
41 |
175-9188
|
Left hand side skirt kit |
$95.15
|
1 |
(includes 26-30) |
usually ships 10-16 days |
