| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
991-8150
|
1/4 inch BH2-61 male nipple (mate to QD80) |
1 |
|
|
002 |
175-6244
|
Nipple |
2 |
|
|
003 |
175-1825
|
Washer |
1 |
|
|
004 |
175-1924
|
Injector |
1 |
|
|
005 |
175-1925
|
1/4 inch brass adapter |
1 |
|
|
006 |
175-1926
|
36 inch pulse hose assembly |
1 |
|
|
007 |
175-1927
|
Vinyl cap |
1 |
|
|
008 |
175-4876
|
PVC hose 1/4 x 12 inch (gray) |
1 |
|
|
009 |
175-1929
|
Solution screen |
1 |
|
|
010 |
175-1930
|
Bladder plate assembly |
1 |
|
|
011 |
999-0016
|
Washer 1/4 flat plain finish |
4 |
|
|
012 |
999-0632
|
Washer 1/4 split lock stainless steel |
4 |
|
|
013 |
999-0334
|
Bolt 1/4-20 x 3/4 inch hex head stainless steel |
4 |
|
|
014 |
997-2001
|
Hose clamp |
2 |
|
|
015 |
175-6552
|
Hose 1/2 x 35 inch |
1 |
|
|
016 |
175-1936
|
Hose 1/4 x 40 inch (OBSOLETE) |
1 |
|
|
017 |
997-2002
|
Hose clamp #6 |
2 |
|
|
018 |
175-1659
|
Fitting |
3 |
|
|
019 |
175-1939
|
Ball valve |
1 |
|
|
020 |
175-1940
|
76 inch tubing (blue) |
1 |
|
|
021 |
175-1941
|
Pressure relief valve |
1 |
|
|
022 |
175-1661
|
90 degree elbow fitting |
1 |
|
|
023 |
175-6029
|
Straight tee |
1 |
|
|
024 |
175-1944
|
Brass bushing |
1 |
|
|
025 |
175-1945
|
Elbow fitting 1/2 x 1/2 inch |
1 |
|
|
026 |
375-2583
|
Water pump kit |
1 |
|
|
027 |
175-1947
|
Elbow fitting 1/2 x 1/2 inch |
1 |
|
|
028 |
175-1918
|
Square keyway |
1 |
|
|
029 |
175-1885
|
1/3 HP pump drive motor |
1 |
|
|
030 |
175-1950
|
Cap 1 gallon bottle (OBSOLETE) |
1 |
|
|
031 |
175-1951
|
Spacer 5/16 x 1/2 |
1 |
|
|
032 |
175-1952
|
Metering tips kit (pkg of 14) |
1 |
|
|
033 |
175-6031
|
Straight jet fitting |
1 |
|
|
