| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
999-0469
|
Nut M6-1 nylon insert lock zinc plated |
2 |
|
|
2 |
275-6686
|
FITTING, BRS, E90 (TENNANT INDUSTRIAL) |
1 |
|
|
4 |
475-7563
|
GROMMET, RBR, 0.19ID, F/0.3H, .19 MATL (Tennant Industrial) |
4 |
|
|
5 |
375-3491
|
Screw (Tennant Industrial) |
4 |
|
|
6 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
4 |
|
|
7 |
175-2894
|
Nut M5-.8 hex nylon locking |
4 |
|
|
8 |
275-0113
|
HOSE, PVC, CLR, 0.38ID 0.56OD 022.0L (Tennant Industrial) |
1 |
|
|
9 |
999-0016
|
Washer 1/4 flat plain finish |
2 |
|
|
10 |
375-3496
|
Bushing (Tennant Industrial) |
1 |
|
|
11 |
375-0473
|
Intake manifold gasket (Tennant Industrial) |
1 |
|
|
12 |
375-0467
|
Intake manifold (Tennant Industrial) |
1 |
|
|
13 |
375-0471
|
12 npt plug stainless steel (Tennant Industrial) |
1 |
|
|
14 |
375-0468
|
Intake manifold plug (Tennant Industrial) |
1 |
|
|
15 |
375-0470
|
Sensor port plug (Tennant Industrial) |
1 |
|
|
16 |
375-3509
|
Bracket (Tennant Industrial) |
1 |
|
|
17 |
375-3510
|
Lock off filter spacer (Tennant Industrial) |
1 |
|
|
18 |
375-0494
|
Hole injector plug |
4 |
|
|
19 |
675-5159
|
VR, SENSOR, SPD, TIMING WHEEL [3.0L] (Tennant Industrial) |
1 |
|
|
20 |
675-6474
|
VR, THROTTLE BODY [MIT , BOSCH] (Tennant Industrial) |
1 |
|
|
21 |
375-3508
|
Module (Tennant Industrial) (OBSOLETE) |
1 |
|
|
22 |
375-3513
|
Fuel trim valve adapter (Tennant Industrial) |
1 |
|
|
23 |
375-3514
|
Plate adapter (Tennant Industrial) |
1 |
|
|
24 |
375-3515
|
Regulator (Tennant Industrial) |
1 |
|
|
25 |
375-3516
|
Mixer (Tennant Industrial) |
1 |
|
|
26 |
375-3536
|
Isolator (Tennant Industrial) |
3 |
|
|
27 |
375-3537
|
Adapter (Tennant Industrial) |
1 |
|
|
28 |
375-3519
|
Cap fitting (Tennant Industrial) |
1 |
|
|
29 |
375-3520
|
Fitting (Tennant Industrial) |
2 |
|
|
30 |
375-3521
|
Hose fitting (Tennant Industrial) |
2 |
|
|
31 |
375-3522
|
Balancing hose (Tennant Industrial) |
1 |
|
|
32 |
375-3523
|
Balancing hose (Tennant Industrial) |
1 |
|
|
33 |
375-3524
|
Vacuum hose fitting (Tennant Industrial) |
1 |
|
|
34 |
375-3525
|
Jet coolant restrictor (Tennant Industrial) |
1 |
|
|
35 |
375-3526
|
Seal (Tennant Industrial) |
2 |
|
|
36 |
375-3527
|
Throttle sleeve (Tennant Industrial) |
1 |
|
|
37 |
375-3528
|
Check valve (Tennant Industrial) |
1 |
|
|
38 |
375-3529
|
Hose (Tennant Industrial) |
1 |
|
|
39 |
375-3530
|
Press trim hose (Tennant Industrial) |
1 |
|
|
40 |
375-3531
|
Hose (Tennant Industrial) |
1 |
|
|
41 |
375-0518
|
Mold hose (Tennant Industrial) |
1 |
|
|
42 |
375-3532
|
Hose (Tennant Industrial) |
1 |
|
|
43 |
375-3533
|
Fitting (Tennant Industrial) |
1 |
|
|
44 |
375-3534
|
Fitting (Tennant Industrial) |
1 |
|
|
45 |
375-3535
|
Nipple fitting (Tennant Industrial) |
1 |
|
|
46 |
375-3518
|
Throttle body adapter (Tennant Industrial) |
1 |
|
|
47 |
375-3538
|
Throttle body seal (Tennant Industrial) |
1 |
|
|
48 |
375-3517
|
Gasket (Tennant Industrial) |
1 |
|
|
49a |
375-3539
|
Fuel lock valve wire connector (Tennant Industrial) |
1 |
(includes 49b) |
|
49b |
375-0513
|
Gas fuelock filter kit (Tennant Industrial) |
1 |
|
|
50 |
375-3540
|
Fuel valve (Tennant Industrial) |
1 |
|
|
51 |
275-6677
|
Fuel valve (TENNANT INDUSTRIAL) |
1 |
|
|
52 |
175-0199
|
Hose clamp |
6 |
|
|
53 |
175-6869
|
FITTING, DRAINCOCK, E90, .25NPT (Tennant Industrial) |
1 |
|
|
54 |
175-3594
|
Hose clamp |
1 |
|
|
55 |
175-0199
|
Hose clamp |
2 |
|
|
56 |
375-0482
|
Air bleed tube (Tennant Industrial) |
1 |
|
|
57 |
375-0483
|
Brass fitting (Tennant Industrial) |
1 |
|
|
