| # | Part | Description |
Req | Notes | Availability |
|---|
0 |
375-1050
|
Spray nozzle kit (Tennant Industrial) |
1 |
(includes 1-32) |
|
1 |
375-1051
|
Diaphragm pump (Tennant Industrial) |
1 |
|
|
2 |
375-1052
|
Pump plate (Tennant Industrial) |
1 |
|
|
3 |
999-1907
|
Screw M5-.8 x 45mm phillips pan head |
4 |
|
|
4 |
999-0006
|
Washer 3/16 flat zinc plated |
4 |
|
|
5 |
175-2894
|
Nut M5-.8 hex nylon locking |
2 |
|
|
6 |
175-9703
|
HOSE, AFMKT, PVC, BRD, 0.50ID, 08FT, CLR (Tennant Industria |
1 |
|
|
7 |
175-0199
|
Hose clamp |
6 |
|
|
8 |
375-1053
|
Water coil hose (Tennant Industrial) |
1 |
|
|
9 |
275-7874
|
Spray gun nozzle |
1 |
|
|
10 |
275-7873
|
Brass fitting |
1 |
|
|
11 |
375-1054
|
Spray handle bracket (Tennant Industrial) |
1 |
|
|
12 |
175-9680
|
Plastic tee fitting |
1 |
|
|
13 |
375-1055
|
Plastic swivel fitting (Tennant Industrial) |
1 |
|
|
14 |
275-0120
|
DPDT rocker switch |
1 |
|
|
15 |
375-1056
|
Spray wand bracket (Tennant Industrial) |
1 |
|
|
16 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
2 |
|
|
17 |
175-7920
|
Washer M8 flat stainless steel |
2 |
|
|
18 |
375-1057
|
Brass fitting (Tennant Industrial) |
1 |
|
|
19 |
175-5241
|
90 degree elbow |
1 |
|
|
20 |
375-1058
|
Clean-out wand (Tennant Industrial) |
1 |
|
|
21 |
375-1011
|
Finger grip clip (Tennant Industrial) |
2 |
|
|
22 |
175-5924
|
Screw 10 x 5/8 hex |
2 |
|
|
23 |
999-0998
|
Washer #10 flat stainless steel |
6 |
|
|
24 |
375-1059
|
Garden hose brass fitting (Tennant Industrial) |
1 |
|
|
25 |
175-2303
|
Rubber washer |
1 |
|
|
26 |
375-1060
|
Garden hose brass fitting (Tennant Industrial) |
1 |
|
|
27 |
375-1061
|
Nozzle spray coupling (Tennant Industrial) |
1 |
|
|
28 |
375-1062
|
Nozzle (Tennant Industrial) |
1 |
|
|
29 |
375-1063
|
Shutoff valve (Tennant Industrial) |
1 |
|
|
30 |
375-1064
|
Spray nozzle harness (Tennant Industrial) |
1 |
|
|
31 |
175-5970
|
RELAY, 12VDC, 040A, SPDT NO (Tennant Industrial) |
1 |
|
|
32 |
375-1065
|
Plastic swivel fitting (Tennant Industrial) |
1 |
|
|
