| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-0990
|
Solution pump (Tennant Industrial) |
1 |
|
|
2 |
375-0991
|
Retainer pump bracket (Tennant Industrial) |
1 |
|
|
3 |
375-0992
|
Retainer pump bracket (Tennant Industrial) |
1 |
|
|
4 |
999-0507
|
Bolt M6-1 x 16mm hex head full thread plain finish |
2 |
|
|
5 |
275-4736
|
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
7 |
|
|
6 |
375-0993
|
FaST bracket (Tennant Industrial) |
1 |
|
|
7 |
175-2888
|
Bolt M8-1 1/4 x 25mm hex head |
2 |
|
|
8 |
175-5313
|
Plastic cap fitting |
1 |
|
|
9 |
175-5311
|
Female fitting with valve |
1 |
|
|
10 |
175-5312
|
Male coupling strainer fitting |
1 |
|
|
11 |
375-0994
|
12V water solenoid valve (Tennant Industrial) |
1 |
|
|
12 |
999-1225
|
Screw M5-.8 x 12mm pan head phillips zinc |
2 |
|
|
13 |
999-0998
|
Washer #10 flat stainless steel |
2 |
|
|
14 |
175-7218
|
Plastic straight fitting |
1 |
|
|
15 |
175-6029
|
Straight tee |
1 |
|
|
16 |
175-6926
|
Plastic elbow fitting |
2 |
|
|
17 |
375-0995
|
FaST bracket (Tennant Industrial) |
1 |
|
|
18 |
375-0996
|
Injector FaST kit (Tennant Industrial) |
2 |
|
|
19 |
175-5970
|
RELAY, 12VDC, 040A, SPDT NO (Tennant Industrial) |
1 |
|
|
20 |
175-3166
|
Bolt M6-1 x 16mm hex head |
1 |
|
|
21 |
275-9305
|
Check valve (Tennant Industrial) |
2 |
|
|
22 |
175-7303
|
1/4 inch union tee |
1 |
|
|
23 |
175-5305
|
Hose 1/4 x 3 foot |
1 |
|
|
24 |
275-1748
|
HOSE, PVC, CLR, 0.38ID 0.56OD 027.0L |
1 |
|
|
25 |
175-6294
|
3 foot hose (clear) (Tennant Industrial) |
1 |
|
|
26a |
175-2222
|
PVC hose |
1 |
(OEM) |
|
26b |
991-1409
|
Clear vinyl tubing 9/16 OD x 3/8 ID inch (sold by the inch) |
9 in |
(NON-OEM) |
|
27 |
175-5240
|
FITTING, PLSTC, Y, BM08/BM08/BM08, NYL (Tennant Industrial) |
1 |
|
|
28 |
175-3594
|
Hose clamp |
6 |
|
|
29 |
375-0997
|
FaST plate (Tennant Industrial) |
1 |
|
|
30 |
275-1534
|
3 foot PVC hose (braided) (Tennant Industrial) |
1 |
|
|
31 |
175-6081
|
Hose clamp |
4 |
|
|
32 |
175-9703
|
HOSE, AFMKT, PVC, BRD, 0.50ID, 08FT, CLR (Tennant Industria |
1 |
|
|
33 |
175-9679
|
90 degree plastic elbow |
1 |
|
|
34 |
175-0664
|
Plastic tee fitting |
1 |
|
|
35 |
175-0663
|
FITTING, PLSTC, STR, PM12/PM12 1.60L (Tennant Industrial) |
1 |
|
|
36 |
175-2523
|
Plastic fitting |
1 |
|
|
38a |
175-9025
|
In-line screen filter assembly |
1 |
|
|
38b |
991-8582
|
Mesh inline filter |
1 |
|
|
39 |
175-4808
|
Hose barb |
2 |
|
|
40 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
2 |
|
|
42 |
275-9302
|
FITTING, NYL, QDC, E90, BM06/ QM10 (Tennant Industrial) |
1 |
|
|
