| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
275-6707
|
Cooler (TENNANT INDUSTRIAL) (OBSOLETE) |
1 |
|
|
2 |
275-0391
|
90 degree elbow hydraulic fitting |
1 |
|
|
3 |
375-0875
|
Hydraulic fitting (Tennant Industrial) |
1 |
|
|
4 |
375-0876
|
Hydraulic fluid bracket weldment (Tennant Industrial) |
1 |
|
|
5 |
275-5558
|
Tank pad (Tennant Industrial) |
4 |
|
|
6 |
275-9575
|
SCREW, HEX, M8 X 1.25 X 25, 9.8, SEMS (Tennant Industrial) |
5 |
|
|
7 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
6 |
|
|
8 |
999-0785
|
Screw M8-1.25 x 30mm hex head stainless steel |
2 |
|
|
9 |
999-0024
|
Washer 5/16 flat stainless steel |
2 |
|
|
10 |
375-0877
|
Bulb seal (Tennant Industrial) |
1 |
|
|
11 |
175-2260
|
P clamp |
1 |
|
|
12 |
999-0665
|
Nut M8-1.25 flange lock |
1 |
|
|
13 |
375-0878
|
Hydraulic cap fitting (Tennant Industrial) |
1 |
|
|
14 |
375-0879
|
Hydraulic squeegee lift tube (Tennant Industrial) |
1 |
|
|
15 |
375-0880
|
Hydraulic squeegee lift tube (Tennant Industrial) |
1 |
|
|
16 |
375-0881
|
2 hold tube clamp (Tennant Industrial) |
2 |
|
|
17 |
999-0779
|
Screw M6-1 x 25mm hex head plain finish |
2 |
|
|
18 |
375-0882
|
Rear squeegee tube (Tennant Industrial) |
2 |
|
|
19 |
375-0883
|
Hydraulic fitting nut (Tennant Industrial) |
2 |
|
|
20 |
375-0884
|
Main return tube (Tennant Industrial) |
1 |
|
|
21 |
175-5314
|
P clamp (Tennant Industrial) |
2 |
|
|
22 |
275-9575
|
SCREW, HEX, M8 X 1.25 X 25, 9.8, SEMS (Tennant Industrial) |
1 |
|
|
23 |
999-0785
|
Screw M8-1.25 x 30mm hex head stainless steel |
1 |
|
|
24 |
275-0391
|
90 degree elbow hydraulic fitting |
1 |
|
|
25 |
375-0875
|
Hydraulic fitting (Tennant Industrial) |
1 |
|
|
26 |
375-0885
|
Hydraulic fitting (Tennant Industrial) |
1 |
|
|
27 |
375-0886
|
Main return tube (Tennant Industrial) |
1 |
|
|
28 |
275-3351
|
FITTING, HYD, E90, JF08/JM08 (Tennant Industrial) |
1 |
|
|
