| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-0820
|
Fan plate weldment (Tennant Industrial) |
1 |
|
|
2 |
375-0821
|
Impeller (Tennant Industrial) |
1 |
|
|
3 |
175-2429
|
Vibration isolator |
3 |
|
|
4 |
675-9750
|
MOTOR, HYD, GEAR, ECT 0.17 LH 3000 (Tennant Industrial) |
1 |
|
|
5 |
999-0503
|
Nut M12-1.75 hex stainless steel |
1 |
|
|
6 |
999-0501
|
Bolt M8-1.25 x 25mm hex head full thread stainless steel |
4 |
|
|
7 |
999-9097
|
Washer M8 flat stainless steel |
7 |
|
|
8 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
4 |
|
|
9 |
375-0823
|
Hydraulic tee fitting (Tennant Industrial) |
1 |
|
|
10 |
275-0395
|
FITTING, HYD, E45, JM08/OM10 (Tennant Industrial) |
1 |
|
|
11 |
275-9450
|
FITTING, HYD, E90, JM06/OM04 (Tennant Industrial) |
1 |
|
|
12 |
175-6787
|
FITTING, HYD, STR, JM08/OM10 (Tennant Industrial) |
1 |
|
|
13 |
375-0824
|
Support fan angle (Tennant Industrial) |
3 |
|
|
14 |
375-0825
|
1 hole cable clamp (Tennant Industrial) |
1 |
|
|
15 |
999-0581
|
Bolt M8-1.25 x 25mm hex head full thread zinc |
3 |
|
|
16 |
175-7920
|
Washer M8 flat stainless steel |
10 |
|
|
17 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
7 |
|
|
18 |
375-0826
|
Radial discharge fan housing (Tennant Industrial) |
1 |
|
|
19 |
375-0827
|
Gasket (Tennant Industrial) |
1 |
|
|
20 |
275-9626
|
PLATE WLDT, HOSE, VACUUM (Tennant Industrial) |
1 |
|
|
21 |
375-0828
|
Gasket (Tennant Industrial) |
1 |
|
|
22 |
999-0785
|
Screw M8-1.25 x 30mm hex head stainless steel |
2 |
|
|
23 |
999-0786
|
Screw M8-1.25 x 35mm hex head stainless steel |
1 |
|
|
24 |
375-0829
|
Foam gasket (Tennant Industrial) |
1 |
|
|
25 |
275-0464
|
Washer 1/2 flat belleville |
1 |
|
|
