| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-0813
|
Water distribution tube (Tennant Industrial) |
1 |
|
|
2 |
275-9567
|
CLAMP, CABLE, SS, 1.12D X 0.38W, 1HOLE (Tennant Industrial) |
4 |
|
|
3 |
999-1225
|
Screw M5-.8 x 12mm pan head phillips zinc |
4 |
|
|
4 |
999-0740
|
Nut M5-.8 hex stainless steel |
4 |
|
|
5 |
675-0367
|
VALVE ASSY, WATER, SOLENOID, 12VDC (Tennant Industrial) |
1 |
|
|
6 |
999-1312
|
Screw M6-1 x 20mm hex head stainless steel |
2 |
|
|
7 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
2 |
|
|
8 |
999-0497
|
Nut M6-1 nylon insert lock stainless steel |
2 |
|
|
9 |
275-8347
|
HOSE, AFMKT, PVC, BRD, 0.75ID, 08FT, CLR (Tennant Industria |
1 |
|
|
10 |
175-0199
|
Hose clamp |
5 |
|
|
11 |
275-9568
|
FITTING, PLSTC, STR, BM12/BM12 (Tennant Industrial) |
1 |
|
|
12 |
175-0680
|
Strain plastic fitting |
1 |
|
|
