| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
175-2366
|
Rubber grommet |
2 |
|
|
2 |
375-0751
|
Trim molding (Tennant Industrial) |
1 |
|
|
3 |
275-7310
|
Cap (Tennant Industrial) |
2 |
|
|
4 |
375-0333
|
Wheel (Tennant Industrial) |
6 |
|
|
5 |
375-0334
|
Wheel pin kit (Tennant Industrial) |
2 |
|
|
6 |
275-0418
|
Cotter pin 5/32 x 2 |
2 |
|
|
7 |
375-0753
|
Press switch (Tennant Industrial) |
1 |
|
|
8 |
275-0684
|
Rubber grommet |
1 |
|
|
9 |
175-5326
|
Screw M4-.7 x 20mm pan head phillips stainless steel |
2 |
|
|
10 |
999-1083
|
Washer #8 internal star lock stainless steel |
2 |
|
|
11 |
175-3366
|
Fitting |
1 |
|
|
12 |
275-3965
|
FITTING, BRS, BREATHER [02MP] (Tennant Industrial) |
1 |
|
|
13 |
375-0754
|
Vacuum hose (Tennant Industrial) |
1 |
|
|
14 |
175-6851
|
FITTING, BRS, E90, BM03/PM02 (Tennant Industrial) |
1 |
|
|
15 |
375-0755
|
Vacuum tube (Tennant Industrial) |
1 |
|
|
16 |
275-9575
|
SCREW, HEX, M8 X 1.25 X 25, 9.8, SEMS (Tennant Industrial) |
2 |
|
|
17 |
375-0756
|
12V tail light assembly (Tennant Industrial) |
2 |
|
|
18 |
375-0399
|
Screw M4 -.7 x 20, 4.8 pan phillips (Tennant Industrial) |
4 |
|
|
19 |
375-0757
|
Lift hopper weldment (Tennant Industrial) |
1 |
|
|
20 |
375-0342
|
Pin (Tennant Industrial) |
2 |
|
|
21 |
375-0341
|
Roll pin (Tennant Industrial) |
2 |
|
|
22 |
375-0343
|
Flat washer (Tennant Industrial) |
2 |
|
|
23 |
375-0344
|
Cotter hair pin |
2 |
|
|
24 |
375-0758
|
Press switch (Tennant Industrial) |
1 |
|
|
