| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-0663
|
Front drive housing kit (Tennant Industrial) |
1 |
|
|
2 |
175-0636
|
BEARING, CUP, 2.56D 0.55W (Tennant Industrial) |
2 |
|
|
3 |
175-6778
|
FITTING, GREASE, STR PM04 .63L (Tennant Industrial) |
2 |
|
|
4 |
375-0664
|
Rear grease cavity seal (Tennant Industrial) |
1 |
|
|
5 |
375-0665
|
Internal hydraulic gear motor (Tennant Industrial) |
1 |
(see breakdowns) |
|
6 |
275-2897
|
FITTING, HYD, STR, JM10/OM12 (Tennant Industrial) |
1 |
|
|
7 |
375-0666
|
Hydraulic fitting (Tennant Industrial) |
1 |
|
|
8 |
375-0667
|
Hydraulic fitting (Tennant Industrial) |
1 |
|
|
9 |
375-0668
|
Screw 1/2-13 x 1 1/2 socket aluminum (Tennant Industrial) |
4 |
|
|
10a |
275-4793
|
HUB ASSY, WHEEL, 5 BOLT 4.50BC TAPER B (Tennant Industrial) |
1 |
(includes 10b) |
|
10b |
375-0669
|
Wheel stud (Tennant Industrial) |
5 |
|
|
11 |
375-0670
|
Cotter pin (Tennant Industrial) |
2 |
|
|
12 |
175-0638
|
BEARING, CONE, 1.38B 0.71W (Tennant Industrial) |
2 |
|
|
13 |
375-0671
|
Washer 2-5/32 flat felt (Tennant Industrial) |
1 |
|
|
14 |
375-0672
|
Washer 1/3/8 flat steel (Tennant Industrial) |
1 |
|
|
15 |
375-0673
|
Bolt 1-3/8 drilled shoulder (Tennant Industrial) |
1 |
|
|
16 |
375-0674
|
Nut 1-1/8-18 hex slotted (Tennant Industrial) |
1 |
|
|
17 |
375-0675
|
Screw M16-2 x 50, 12.9 socket (Tennant Industrial) |
2 |
|
|
18 |
175-6797
|
NUT, WHEEL, .50-20 X 60 ANGLE (Tennant Industrial) |
5 |
|
|
19a |
375-0677
|
Hydraulic cylinder (Tennant Industrial) |
1 |
|
|
19b |
375-0677
|
Hydraulic cylinder (Tennant Industrial) |
1 |
|
|
20 |
375-0678
|
Hydraulic fitting (Tennant Industrial) |
2 |
|
|
21 |
375-0679
|
Round tube (Tennant Industrial) |
1 |
|
|
22 |
375-0680
|
Screw 3/4-10 x 4 G5 hex (Tennant Industrial) |
2 |
|
|
23a |
999-0630
|
Washer 3/4 SAE flat |
2 |
|
|
23b |
375-0681
|
Washer flat steel (Tennant Industrial) |
2 |
|
|
24 |
275-2942
|
NUT, HEX, LOCK, .75-10, NL (Tennant Industrial) |
2 |
|
|
25 |
375-0682
|
Flat steel bar (Tennant Industrial) |
1 |
|
|
26 |
999-1133
|
Bolt M8-1.25 x 20mm hex head full thread plain |
2 |
|
|
27 |
999-0024
|
Washer 5/16 flat stainless steel |
2 |
|
|
28 |
375-0683
|
Tube (Tennant Industrial) |
1 |
|
|
29 |
375-0684
|
Nylon sleeve (Tennant Industrial) |
2 |
|
|
30 |
175-2162
|
Nylon wire tie |
1 |
|
|
31 |
275-7333
|
TIRE ASSY, SOLID, 18.0 X 6.0,HI TRACTION (Tennant Industrial |
1 |
|
|
32 |
375-0685
|
Tire assembly (Tennant Industrial) |
1 |
(optional polyurethene) |
|
33 |
375-0686
|
Front wheel housing (Tennant Industrial) (OBSOLETE) |
1 |
|
|
34 |
375-0687
|
Screw 3/4-10 x 3 1/4 hex head grade 5 (Tennant Industrial) |
2 |
|
|
35 |
375-0688
|
Support bracket (Tennant Industrial) |
1 |
|
|
36 |
375-0689
|
Nylon sleeve (Tennant Industrial) |
1 |
|
|
37 |
175-2162
|
Nylon wire tie |
2 |
|
|
