| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-0535
|
Shield muffler channel (Tennant Industrial) |
1 |
|
|
2 |
999-1312
|
Screw M6-1 x 20mm hex head stainless steel |
2 |
|
|
3 |
999-0016
|
Washer 1/4 flat plain finish |
4 |
|
|
4 |
375-0609
|
Exhaust replacement pipe kit (Tennant Industrial) |
1 |
|
|
5 |
275-7137
|
Nut M10 x 1.5mm hex stover (TENNANT INDUSTRIAL) |
4 |
|
|
6 |
275-7321
|
VR, SENSOR, EXHAUST, TAILPIPE (Tennant Industrial) |
1 |
|
|
7 |
275-6408
|
Gasket (TENNANT INDUSTRIAL) |
2 |
|
|
8 |
175-3258
|
Bolt M10-1.5 x 35mm hex head |
4 |
|
|
9 |
375-0610
|
Catalytic muffler (Tennant Industrial) |
1 |
|
|
10 |
375-0611
|
Flanged exhaust tube (Tennant Industrial) |
1 |
|
|
11 |
375-0541
|
Muffler bracket (Tennant Industrial) |
1 |
|
|
12 |
375-0542
|
Isolator hanger rod (Tennant Industrial) |
1 |
|
|
13 |
999-0032
|
Washer 3/8 USS flat plain finish |
2 |
|
|
14 |
999-1281
|
Nut M10-1.25 hex fine thread |
2 |
|
|
15 |
375-0543
|
Rubber isolator (Tennant Industrial) |
1 |
|
|
16 |
175-2182
|
Sleeve |
1 |
|
|
17 |
175-2854
|
Screw M8-1.25 x 45mm hex head stainless steel |
1 |
|
|
18 |
999-9097
|
Washer M8 flat stainless steel |
2 |
|
|
19 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
1 |
|
|
20 |
375-0612
|
Drip tray shield (Tennant Industrial) |
1 |
|
|
21 |
999-0502
|
Bolt M6-1 x 20mm hex head full thread zinc |
3 |
|
|
22 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
1 |
|
|
23 |
375-0613
|
Muffler bracket (Tennant Industrial) |
1 |
|
|
24 |
275-4518
|
NUT, HEX, STOVER, M8 X 1.25 (Tennant Industrial) |
3 |
|
|
25 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
3 |
|
|
