| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-0466
|
Relay box isolator (Tennant Industrial) |
2 |
|
|
2 |
999-0821
|
Bolt 1/4-20 x 1/2 hex head grade 9 yellow zinc |
2 |
|
|
3 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
4 |
|
|
4 |
999-0190
|
Nut 1/4-20 hex plain finish |
2 |
|
|
5 |
375-0581
|
Brass fitting (Tennant Industrial) |
1 |
|
|
6 |
375-0582
|
Brass fitting (Tennant Industrial) |
1 |
|
|
7 |
375-0583
|
Spring hose clamp (Tennant Industrial) |
2 |
|
|
8 |
375-0584
|
Brass fitting (Tennant Industrial) |
1 |
|
|
9 |
375-0585
|
Brass fitting (Tennant Industrial) |
1 |
|
|
10 |
375-0586
|
Rubber heater hose (Tennant Industrial) |
1 |
|
|
