| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-0568
|
Coolant mold hose (Tennant Industrial) |
1 |
|
|
2 |
997-2003
|
Hose clamp |
1 |
|
|
3 |
997-2000
|
Hose clamp |
2 |
|
|
4 |
275-7308
|
Hose (Tennant Industrial) |
1 |
|
|
5 |
375-0569
|
Lower coolant tube (Tennant Industrial) |
1 |
|
|
6 |
275-7311
|
Radiator hose (Tennant Industrial) |
1 |
|
|
7 |
175-6869
|
FITTING, DRAINCOCK, E90, .25NPT (Tennant Industrial) |
1 |
|
|
8 |
275-0113
|
HOSE, PVC, CLR, 0.38ID 0.56OD 022.0L (Tennant Industrial) |
1 |
|
|
9 |
175-3594
|
Hose clamp |
3 |
|
|
10 |
375-0570
|
1 liter coolant tank (Tennant Industrial) |
1 |
|
|
11a |
375-0571
|
Coolant recovery hose (Tennant Industrial) |
1 |
|
|
11b |
375-0572
|
Fuel hose (Tennant Industrial) |
1 |
|
|
12 |
999-1133
|
Bolt M8-1.25 x 20mm hex head full thread plain |
2 |
|
|
13 |
175-9979
|
Clamp (Tennant Industrial) |
1 |
|
|
14 |
999-0501
|
Bolt M8-1.25 x 25mm hex head full thread stainless steel |
1 |
|
|
15 |
999-9097
|
Washer M8 flat stainless steel |
2 |
|
|
16 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
1 |
|
|
17 |
375-0573
|
Coolant tube bracket (Tennant Industrial) |
1 |
|
|
18 |
275-9575
|
SCREW, HEX, M8 X 1.25 X 25, 9.8, SEMS (Tennant Industrial) |
1 |
|
|
19 |
999-0024
|
Washer 5/16 flat stainless steel |
2 |
|
|
20 |
375-0574
|
1 liter coolant tank (Tennant Industrial) |
1 |
|
|
21 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
2 |
|
|
