| # | Part | Description |
Req | Notes | Availability |
|---|
1a |
375-3135
|
24 inch polypropelene sweeping brush (TENNANT INDUSTRIAL) |
1 |
(includes 2-6) |
|
1b |
991-2428
|
24 inch side poly brush |
1 |
(NON-OEM) |
|
2 |
175-2335
|
Brush adaptor |
1 |
|
|
3 |
175-2071
|
Brush retaining spring |
1 |
|
|
4a |
175-2072
|
Spring retainer bracket |
1 |
|
|
4b |
991-3047
|
Spring retainer bracket |
1 |
(NON-OEM) |
|
5 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
1 |
|
|
6 |
175-0505
|
Screw M6-1 x 35mm pan head stainless steel |
3 |
|
|
8 |
275-4936
|
Brush hub 3 hole |
1 |
|
|
