# | Part | Description | Price | Req | Notes | Availability |
1 |
275-6446
|
Brush motor cover |
$35.10
|
1 |
|
usually ships 1-5 days |
2 |
175-0287
|
Acrylic foam tape 1 inch x 1 foot |
$13.70
|
2 |
|
usually ships 6-16 days |
3 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
$1.08
|
1 |
|
ships same day |
4 |
999-0024
|
Washer 5/16 flat stainless steel |
$1.34
|
1 |
|
ships same day |
5 |
175-2249
|
Sleeve |
$3.08
|
1 |
|
usually ships 6-16 days |
6a |
175-7919
|
Guide wheel |
$4.95
|
1 |
(OEM) |
ships same day |
6b |
991-8570
|
Bumper wheel |
$2.81
|
1 |
(NON-OEM) |
ships same day |
7 |
999-0770
|
Screw M8-1.25 x 30mm flat head socket stainless steel |
$2.62
|
1 |
|
ships same day |
8 |
175-3718
|
Knob |
$3.96
|
1 |
|
ships same day |
9 |
275-5914
|
Compression spring |
$9.35
|
1 |
|
ships same day |
10 |
275-5915
|
Nut M14 x 2mm hex head stainless steel |
$3.96
|
1 |
|
ships same day |
11 |
275-9252
|
24V 1HP brush motor assembly |
$1,322.90
|
1 |
(includes 12 and 13) |
ships same day |
12a |
175-2600
|
Carbon brush |
$30.80
|
4 |
(before SN 10572326) |
ships same day |
12b |
275-5907
|
Carbon brush replacement kit (pkg of 4) |
$10.70
|
1 |
(after SN 10572325) |
usually ships 6-16 days |
13a |
275-5910
|
Square keyway |
$4.29
|
1 |
(before SN 10572326) |
ships same day |
13b |
275-1468
|
Square keyway |
$3.96
|
1 |
(after SN 10572325) |
ships same day |
14 |
999-0777
|
Screw M4-.7 x 10mm hex head plain finish |
$0.99
|
1 |
|
ships same day |
15 |
999-1083
|
Washer #8 internal star lock stainless steel |
$0.99
|
1 |
|
ships same day |
16 |
175-5797
|
Washer 1/6 flat zinc |
$3.30
|
1 |
|
ships same day |
17 |
175-3671
|
Hose clamp |
$3.96
|
1 |
|
ships same day |
18 |
175-7913
|
Solution tube |
$149.71
|
1 |
|
usually ships 6-16 days |
19 |
275-6447
|
Scrub head housing with decal |
$595.10
|
1 |
(includes 20) |
usually ships 1-5 days |
20 |
175-1238
|
Moving parts decal |
$5.28
|
1 |
|
ships same day |
21 |
175-7923
|
17 inch (430mm) bumper with bristle skirt |
$78.87
|
1 |
|
usually ships 6-16 days |
22 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.99
|
4 |
(before SN 10572326) |
ships same day |
23 |
175-4494
|
Washer M10 |
$3.30
|
4 |
(before SN 10572326) |
usually ships 6-16 days |
24 |
999-0562
|
Bolt 3/8-16 x 1 hex head stainless steel |
$1.50
|
4 |
(before SN 10572326) |
ships same day |
25 |
999-1225
|
Screw M5-.8 x 12mm pan head phillips zinc |
$0.99
|
2 |
|
ships same day |
26 |
999-1026
|
Washer #10 internal lock stainless steel |
$0.99
|
2 |
|
ships same day |
27 |
999-0998
|
Washer #10 flat stainless steel |
$0.99
|
2 |
|
ships same day |
28 |
175-7921
|
Brush plate clamp |
$20.79
|
1 |
|
ships same day |
29 |
175-7924
|
Spring clip |
$6.60
|
1 |
|
ships same day |
30a |
275-4800
|
Drive hub |
$229.57
|
1 |
(before SN 10572326) |
usually ships 6-16 days |
30b |
275-9256
|
Drive hub |
$237.16
|
1 |
(after SN 10572325) |
ships same day |
31 |
999-0688
|
Bolt 5/16-18 x 1 1/4 hex head stainless steel |
$0.99
|
1 |
(before SN 10572326) |
ships same day |
32 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
$0.99
|
1 |
(before SN 10572326) |
ships same day |
33 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
$0.99
|
1 |
(before SN 10572326) |
ships same day |
34 |
175-7917
|
Water containment ring |
$9.13
|
1 |
|
ships same day |
35 |
175-1437
|
Spacer |
$9.46
|
2 |
(before SN 10572326) |
ships same day |
36 |
275-5913
|
Pin |
$26.40
|
1 |
|
usually ships 6-16 days |
37 |
175-4701
|
Pin head |
$19.36
|
1 |
|
usually ships 6-16 days |
38 |
175-6617
|
Cable tie |
$6.01
|
1 |
|
usually ships 6-16 days |
39 |
275-1469
|
Shaft spacer |
$8.03
|
1 |
(after SN 10572325) |
ships same day |
40 |
175-7920
|
Washer M8 flat stainless steel |
$3.30
|
1 |
(after SN 10572325) |
ships same day |
41 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
$1.85
|
1 |
(after SN 10572325) |
ships same day |
42 |
275-4736
|
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$3.30
|
1 |
(after SN 10572325) |
ships same day |
N/S |
675-9914
|
Drive hub 3 lug |
$113.80
|
1 |
|
ships same day |
