| # | Part | Description | Price | Req | Notes | Availability |
|---|
1a |
375-1274
|
Control panel assembly with decals |
$400.73
|
1 |
(includes 2 and 3) (before SN 10675132) |
usually ships 1-5 days |
1b |
375-1274
|
Control panel assembly with decals |
$400.73
|
1 |
(includes 2 and 3) (after SN 10675131) |
usually ships 1-5 days |
2 |
275-6434
|
Top control panel decal |
$12.98
|
1 |
|
usually ships 1-5 days |
3 |
275-6435
|
Bottom control panel decal |
$11.22
|
1 |
|
usually ships 1-5 days |
4a |
175-7872
|
Key switch with 2 keys |
$53.13
|
1 |
(includes 5) |
ships same day |
4b |
991-5161
|
Key switch with key and ring |
$16.04
|
1 |
(NON-OEM) |
ships same day |
5 |
991-1634
|
Key (pkg of 2) |
$14.21
|
1 |
|
ships same day |
6 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
$3.96
|
6 |
|
ships same day |
7 |
275-9900
|
Hour meter |
$57.64
|
1 |
|
ships same day |
8 |
175-0085
|
Strain relief bushing |
$4.49
|
1 |
|
usually ships 1-5 days |
9 |
999-0954
|
Nut M4-.7 nylon insert lock stainless steel |
$0.99
|
2 |
|
ships same day |
10 |
991-2103
|
50amp charger plug SB50 with pins (red) |
$7.19
|
1 |
|
ships same day |
11 |
175-1197
|
Plate |
$7.37
|
1 |
|
usually ships 10-16 days |
12 |
999-1673
|
Screw M4-.7 x 25mm pan head phillips stainless steel |
$0.99
|
2 |
|
ships same day |
13 |
999-1221
|
Screw M3-.5 x 25mm pan head stainless steel |
$0.99
|
2 |
|
ships same day |
14 |
999-1158
|
Washer #6 flat stainless steel |
$0.99
|
2 |
|
ships same day |
15 |
175-4273
|
Switch |
$15.84
|
1 |
|
ships same day |
16 |
175-7839
|
Switch plate |
$36.08
|
1 |
|
usually ships 10-16 days |
17 |
175-5705
|
30amp circuit breaker |
$20.68
|
1 |
(brush motor) |
ships same day |
18 |
999-0740
|
Nut M5-.8 hex stainless steel |
$0.99
|
3 |
|
ships same day |
19 |
999-0998
|
Washer #10 flat stainless steel |
$0.99
|
3 |
|
ships same day |
20a |
275-4717
|
100amp relay |
$60.83
|
1 |
(before SN 10675132) |
usually ships 9-14 days |
20b |
375-1275
|
150amp relay |
$50.27
|
1 |
(after SN 10675131) |
usually ships 10-16 days |
21 |
175-6588
|
24V 70amp elevated relay |
$18.92
|
1 |
|
ships same day |
22 |
999-0807
|
Screw M6-1 x 10mm flat head phillips |
$2.49
|
1 |
|
ships same day |
23 |
175-4544
|
Washer M6 locking |
$4.49
|
1 |
|
ships same day |
24 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
3 |
|
ships same day |
25 |
175-7864
|
Wire stand off |
$18.92
|
1 |
|
usually ships 10-16 days |
26 |
999-1161
|
Nut M3-.5 hex nylock stainless steel |
$0.99
|
2 |
|
ships same day |
27 |
275-6436
|
24V battery indicator |
$298.98
|
1 |
|
usually ships 10-16 days |
